10
MULTIGATE PRO XR4400
For the first time, the MULTIGATE PRO XR4400 uses SMD technology (Surface Mounted Device). These
sub-miniature components known from aerospace technology allow for an extreme packing density, plus the
unit’s reliability could be improved. Additionally, the unit is manufactured in compliance with a ISO9000 certi-
fied management system.
2.2 Inputs and outputs
2.2.1 Balanced inputs and outputs
As standard, the BEHRINGER MULTIGATE PRO is installed with electronically servo-balanced inputs and
outputs. The new circuit design features automatic hum and noise reduction for balanced signals and thus
allows for trouble-free operation, even at high operating levels. Externally induced mains hum etc. will be
effectively suppressed. The automatic servo-function recognizes the presence of unbalanced connectors and
adjusts the nominal level internally to avoid level differences between the input and output signals (correction
6 dB).
3. INSTALLATION
Your BEHRINGER MULTIGATE PRO was carefully packed in the factory and the packaging was designed to
protect the unit from rough handling. Nevertheless, we recommend that you carefully examine the packaging
and ist contents for any signs of physical damage, which may have occurred in transit.
+
If the unit is damaged, please do not return it to us, but notify your dealer and the shipping
company immediately, otherwise claims for damage or replacement may not be granted.
Shipping claims must be made by the consignee.
Please take the time to complete and return the warranty card within 14 days of the date of purchase, other-
wise you will lose the right to the extended warranty. Or just use our online-registration (www.behringer.com).
3.1 Rack mounting
The BEHRINGER MULTIGATE PRO fits into one standard 19" rack unit of space (1 ¾"). Please allow at least
an additional 4" depth for the connectors on the back panel. Be sure that there is enough air space around the
unit for cooling and please do not place the MULTIGATE PRO on high temperature devices such as power
amplifiers etc. to avoid overheating.
3.2 Mains voltage
Before you connect your MULTIGATE PRO to the mains, please make sure that your local voltage
matches the voltage required by the unit! The fuse holder on the female mains connector has 3 triangular
markers, with two of these triangles opposing each other. Your MULTIGATE RPO is set to the operating
voltage printed next to these markers, and can be set to another voltage by turning the fuse holder by 180°.
CAUTION: this instruction does not apply to export models exclusively designed, e.g. for 115 V op-
eration!
3.3 Audio connections
The audio inputs and outputs on the BEHRINGER MULTIGATE PRO are fully balanced. If possible, connect
the unit to other devices in a balanced configuration to allow for maximum interference immunity.
+
Please ensure that only qualified persons install and operate the MULTIGATE PRO. During
installation and operation the user must have sufficient electrical contact to earth.
Electrostatic charges might affect the operation of the MULTIGATE PRO!
