1186533 R
EV
1 (02/06)
P
AGE
21
OF
28
P
ARTS
The following table describes the serviceable parts. For parts not listed, contact a Blodgett Range Authorized Parts
Distributor or a Blodgett Range Authorized Service Agency.
PARTS LIST B36-CM
PARTS LIST B36-CM
Part Number
DESCRIPTION
Qty.
Part Number
DESCRIPTION
Qty.
1183202
BODY SIDE, LEFT
1
1183315
NIPPLE,PIPE, BLK. 3/8" X 7.50"
1
1183323
BODY SIDE, RIGHT
1
1183259
TUBE, BURNER SUPPLY (H)
2
1183332
BRACKET, ORFICE
4
1187779
KNOB, VALVE ADJUST
2
1187619
FRONT, BODY
1
1187778
POLYPANEL, NFR/CM
2
1183208
BASE, AZ
1
1164085
VALVE ASM, PILOT
1
1183209
GREASE DRAWER, BA
1
1188253
NAMEPLATE, NEW SB 11.00"
1
1183210
BODY, BOTTOM/BACK
1
1183256
TUBE, VALVE SUPPLY
1
1183219
STIFFENER, CAVITY
1
1187780
RACK, CM-36
1
1183262
COVER
1
1187785
RACK GUIDE, 5 POS.
2
1183263
PLATE, HEAT DEFLECTOR
1
(NAT GAS COMPONENTS)
1187604
SUPPORT, REAR
1
1133301
REGULATOR,WC @ 4" NAT
1
1183257
MOUNT, BURNER
1
1187723
VALVE, BURNER HI-LO
2
1183220
DEFLECTOR, FLUE
1
1008754
ORIFICE HOOD, DRILL # 54
4
1183246
ASM, BURNER
4
1182628
PILOT ASSY
2
1183251
W/A, MANIFOLD
2
(PROP GAS COMPONENTS)
1183330
ASM, MANIFOLD, BURNER
2
1165704
REGULATOR, WC @ 10",PRO
1
1187624
ASM, INNER LINING
1
1187723
VALVE, BURNER HI-LO
2
1183248
TUBE, BURNER SUPPLY (V)
2
1008764
ORIFICE HOOD, DRILL # 64
4
1183264
TUBE, PILOT ADJUST
1
1182628
PILOT ASSY
2
1183310
TUBE, FLEX 1/4 x 16" LG
2
1186533
MANUAL, CM
1
PARTS LIST B48-CM
Qty.
PARTS LIST B48-CM
Qty.
Part Number
DESCRIPTION
P48
Part Number
DESCRIPTION
P48
1183202
BODY SIDE, LEFT
1
1183186
TUBE, BURNER SUPPLY (CNTR)
2
1183323
BODY SIDE, RIGHT
1
1185226
TUBE 1/4" X 2" (PILOT)
1
1183332
BRACKET, ORFICE
6
1187779
KNOB, VALVE ADJUST
2
1187621
FRONT, BODY
1
1187778
POLYPANEL, NFR/CM
2
1183142
BASE, AZ
1
1164085
VALVE ASM, PILOT
1
1183144
GREASE DRAWER, BA
2
1188253
NAMEPLATE, NEW SB 11.00"
1
1183141
BODY, BOTTOM/BACK
1
1183158
TUBE, VALVE SUPPLY
1
1183145
STIFFENER, CAVITY
1
1187782
RACK, CM-48
1
1183161
COVER
1
1187785
RACK GUIDE, 5 POS.
2
1183159
PLATE, HEAT DEFLECTOR
1
(NAT GAS COMPONENTS)
1187606
SUPPORT, REAR
1
1133301
REGULATOR,WC @ 4" NAT
1
1183171
MOUNT, BURNER
1
1187723
VALVE, BURNER HI-LO
2
1183169
DEFLECTOR, FLUE
1
1008754
ORIFICE HOOD, DRILL # 54
6
1183246
ASM, BURNER
6
1182628
PILOT ASSY
3
1183251
W/A, MANIFOLD
2
1183331
ASM, MANIFOLD, BURNER
2
(PROP GAS COMPONENTS)
1187625
ASM, INNER LINING
1
1165704
REGULATOR, WC @ 10",PRO
1
1183248
TUBE, BURNER SUPPLY (V)
2
1187723
VALVE, BURNER HI-LO
2
1183264
TUBE, PILOT ADJUST
1
1008764
ORIFICE HOOD, DRILL # 64
6
1183310
TUBE, FLEX 1/4 x 16" LG
3
1182628
PILOT ASSY
3
1183315
NIPPLE,PIPE, BLK. 3/8" X 7.50"
1
1183185
TUBE, BURNER SUPPLY (H)
2
1186533
MANUAL, CM
1
