BLODGETT
www.blodgett.com
1100 Old Honeycutt Road Fuquay-Varina, NC 27526 USA
Phone: (877) 255-3976 • Fax: (866) 644-1354
SPECIFY
Gas Type Natural Gas Propane
Manifold Front (1-1/4”) Rear (1”)
Flue Riser Height 5” 24” (option) 36” (option)
Range Depth Standard Deep (option)
Position in Battery Left End Right End Not at End
Electric Power (ovens) 120V 208/240V
Operating altitude (if above 2000 ft (700 meters) _____________________
Blodgett can often accommodate special or custom requirements. Contact your
Blodgett representative.
STANDARD FEATURES ( All models )
Four open-top 45,000 BTU burners with separate controls
Removable welded grates
5” flue riser
7" stainless-steel front rail with “belly bar”
Standard range depth
Battery end-units have solid side (no manifold cover plate)
Stainless-steel front and sides
Fully insulated lining and burner boxes
6" adjustable legs (except on modular range-top model)
Warranty: two year parts and labor from date of purchase
STANDARD FEATURES (Convection & Standard Ovens )
45,000 BTU oven with standing pilot (optional electronic ignition available)
Cool-to-the-touch oven handle
Recessed oven control panel for added reliability
Standard-oven interior is 14" high, 26" wide, 26.5" deep (so sheet pans fit
either way)
Two oven racks (2-1/4" between each of five positions)
“Insta-On” thermostat with a wide range of 150°F to 500°F
Convection-oven models have 1/3 hp, two-speed blower
Porcelain enamel oven interior
STANDARD FEATURES ( Base Cabinets )
Dual side-by-side stainless-steel doors
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Flue riser
24”
36”
Single-shelf (mounts on 24” flue riser)
Solid shelf
Tubed shelf
Double-shelf (mounts on 36” flue riser)
Solid shelves
Tubed shelves
Stainless-steel back
Deep range depth
Additional oven racks
Bolt down flange feet
Casters (in lieu of legs)
Open frame base with casters
Cable restraint kit for units on casters
B36-XX
36” Heavy Duty Sectional Range with
Four Open-Top 45K BTU Burners
MODEL
B36-XX
Project
Item No.
Quantity
Model B36A-XX (Convection Oven Base)
Model B36D-XX (Standard Oven Base)
Model B36C-XX (Cabinet Base)
Model B36N-XX (Modular Range-Top)
The Blodgett 36" wide sectional-range with four open-top burners is avail-
able with a choice of three types of base (a convection oven, a standard
oven, or a storage cabinet) or with no base (for mounting as a modular
range-top). Three flue-riser heights are available, and the flue riser can
support up to 250 pounds (for an optional shelf, salamander-broiler, or
cheese melter). An optional rearward-extending flue riser is available to
increase the overall depth to match a deep battery. Battery-design assis-
tance is available!
Model B36A-XX with 24” Flue Riser
