DVI-D CAT X KVM-EXTENDER
22
2
nd
local DVI-Monitor
port Connect to Local
console 2
nd
monitor
Connect to CPU:
2
nd
DVI-Graphic card
local 1
st
DVI-Monitor
port Connect to Local
console 1
st
monitor
Connect to CPU:
USB
Connect to CPU:
1
st
DVI-Graphic card
DVI-D Cat X KVM-Extender Type ACS4201A Local Unit
2
nd
remote DVI-Monitor
port Connect to Remote
console 2
nd
monitor
1
st
remote DVI-
Monitor port– connect
to Remote console 1
st
monitor
Remote keyboard/ mouse
port
DVI-D Cat X KVM-Extender Type ACS4201A Remote Unit
