Fleet operators/Hirers
• Documentation of operational commitments
• Minimization of downtimes
• Rapid support from the manufacturers
• Optimized economic operation of the machine park
• Complete fleet management all from one source for different types of machine,
including equipment from other manufacturers.
• Even better planning reliability: You always know where your machines are,
and whether they are being used economically.
• Support thanks to a maintenance management system tailored especially to tower cranes
• Efficient commitment of the cranes for longer lifespan
• Overloads are identified
• Automatically generated reports about degrees of utilization and the operational
commitment of the machine park.
• Reports can be called up at any time via the Web portal.
• Flexible interaction of the fleets thanks to grouping arrangements (e.g. site by site)
• Regional boundaries (Geofence) and overview of the operational commitment times
• LiDAT data can be drawn on as the basis for the calculation of hire rates
• Freely-selectable data transfer intervals
Service
• On-line notifications in the event of critical operational states
• Costs reduced thanks to efficient erection engineer commitment and spare parts planning,
with direct access to every crane
• Optimization of spare parts dispositions; always the right part on board
• Maintenance planning matched to machine availability
• Support for on-site personnel thanks to on-line diagnosis
• Automated service interval reminders
The LiDAT advantages Machine data acquisition
LiDAT
The complete vehicle park and fleet
management system from Liebherr
LiDAT provides you with the important data specific to
the particular cranes for the series EC-B, EC-H, HC-L,
HC, MK, and the very latest fast-erecting cranes as
well. You also receive any error or warning messages
from your crane. This data is updated automatically
and regularly, which means that the most up-to-date
information is always available. You have access to the following crane data:
• Lifting capacity tables
• Load cycles
• Load moment cycles
• Overload messages
• Wind warnings
• Operating hours
• Event messages
• Scaling data
• and much more besides
Load cycles - O
verload messa
ges - Wind war
nings
Operating hou
rs - Event mes
sages
Liebherr-Werk Biberach GmbH
Postfach 1663, D-88396 Biberach an der Riß
 +49 (0)7351 41-0, Fax +49 (0)7351 41-22 25
www.liebherr.com, E-Mail: [email protected]
Printed in Germany by Eberl BK LBC-720-3-01.12_enGB Subject to technical modifications. This information is supplied without liability.
Liebherr Industrias Metálicas, S.A.
Polígono Industrial Agustinos, c\ E, E-31014 Pamplona
 +34 948 29 70 00, Fax +34 948 29 70 29
www.liebherr.com, E-Mail: [email protected]
LiDAT packages and features
LiDAT is available in the basic packages of LiDAT Basic and LiDAT Plus, as well as the forthcoming additional pack-
ages for LiDAT Plus. The basic package, LiDAT Basic, was designed for the operation of Liebherr-Fr.tronic cranes,
contactor-controlled cranes, and cranes from other manufacturers. LiDAT Plus and the individual additional pack-
ages have been developed especially for the extended technical possibilities of Liebherr-Litronic cranes.
Vehicle park and fleet management
• Can be used for Liebherr cranes and cranes from other manufacturers as well
• Efficient machine commitment planning and administration
• Site and machine commitment planning with freely-definable working ranges and machine groups
• Analysis of the degree of machine utilization, with records and reports on machine use
• Worldwide location of the machine position
• Database for optimized vehicle park management
Maintenance management
• Automatic reminder of maintenance activities, such as gearbox oil changes
or maintenance work on brakes
• Increased availability of cranes thanks to efficient planning of maintenance activities.
• Pre-defined maintenance profiles, especially tailored to the crane type,
with reminder function for maintenance activities
• Possibility of creating additional individual maintenance profiles
• Date planning for acceptance procedures, such as expert assessment inspections or appraisals
Machine data analysis LiDAT functions
Commitment plan
• Efficient planning of machine commitments
and maintenance dates and times
• Faster overview of current operational
commitments, with commitment location,
place, and time
• Overview of the machines currently
available
• Effective working thanks to a number
of different filter possibilities
Report overview
• Overview of all available reports
• Reports specifically tailored to relate to tower cranes
• Automatically generated reports can be taken over
and saved in other formats
Inputting parameters
• Find information fast thanks
to specific parameter input
• Reports can be produced
rapidly and easily
• Fast comparison of times,
machines, and sites
Card overview
• Overview of the distri-
bution of cranes com-
mitted to operations
• Optimization of travel
routes of service
technicians
• Indication of machines
presenting a warning
message (red)
Operating parameters LiDAT Basic LiDAT Plus
Machine position data  
Operating and utilisation times  
Service interval information  
Machine employment planning  
Machine leasing  
Machine management  
Possibilities of manual data request  
Monitoring of geographical application area 
Monitoring of operating times 
Critical operating condition messages 
Error messages / Alarms 
Performance characteristic data 
Data transfer intervals freely configurable freely configurable
Number of data transfers 5 times daily 5 times daily
LiDAT keeps you informed about
your cranes – any time, all the time
LiDAT is a data transfer and location system for Liebherr
cranes and cranes from other manufacturers as well.
And you can just as easily manage complete machin-
ery fleets, fleets of cranes, of earthmoving equipment,
and maritime machinery as well. Based on the very lat-
est data transfer technology, LiDAT provides informa-
tion about the location and operation of the machines,
and that makes efficient management, optimized plan-
ning for commitment, and remote monitoring all easily
possible. With LiDAT, all the important machine data can be ac-
cessed at any time. Depending on the subscription
status, the data is updated several times a day, and
can be called up at any time using a Web browser. And,
if required, particularly important information, such as
information about specific operating states and opera-
tional parameters, can be sent to your E-mail account.
