Transport complete
The transport weight includes the basic machine (ready for operation),
17,000 lbs counterweight and leader without working tools (such as
drilling drive and torque support).
Dimensions and weights*
Leader length 60 ft 70 ft 80 ft
Weight complete in lbs 144,400 146,400 148,400
Transport basic machine
The transport weight includes the basic machine (ready for
operation). Counterweight 17,000 lbs
Weights*
Basic machine in lbs 74,500
Counterweight in lbs 17,700
Transport dimensions and weights
Transport leader
The transport weight includes the leader without working tools (such as
drilling drive and torque support).
Dimensions and weights*
Leader length 60 ft 70 ft 80 ft
Weight of leader in lbs 52,900 54,900 56,900
LRB 155 3
* Indicated dimensions and weigths do not include options!
