24
Changing over door hinges
Door hinges should only be changed by a trained expert.
Changing the door hinges must be done by two people.
3. Slide red safety bracket over
the hinge.
The two knobs on the safety
bracket must be fully insert-
ed into the marked openings
on the hinge.
1. Open door as far as possible.
2. Remove cover.
1
2
3
4
5
6
6
4. Remove pin.
5. Pivot soft stop mechanism to
the right.
6. Remove screws.
WARNING!
Do not move the front section of the soft stop
mechanism in the direction indicated when
the safety bracket has been removed.
The hinge may be closed suddenly by the
strong integrated spring mechanism. This can
cause serious hand or finger injuries.
7
7. Remove red safety bracket.
