24

R 924 Litronic

Backhoe Bucket

with Offset Mono Boom 5.70 m and Heavy Counterweight

Operating Weight

and Ground Pressure

Operating weight includes basic machine with heavy counterweight,
offset mono boom 5.70 m, stick 2.40 m, quick coupler 48 and bucket
0.95 m

3

.

Undercarriage

NLC

SLC

Pad width

mm 500

600

750

500

600

750

Weight

kg 25,450 25,700 26,300 25,550 25,800 26,400

Ground pressure

kg/cm

2

0.64 0.54 0.44

0.65 0.55 0.45

Undercarriage

LC

WLC

Pad width

mm 500

600

750

500

600

750

Weight

kg 25,600 25,850 26,450 26,250 26,500 27,250

Ground pressure

kg/cm

2

0.65 0.55 0.45

0.63 0.53 0.44

Digging Envelope

with Quick Coupler

5

6

7

8

Stick length

m 2.40

2.70

3.00

3.70

Max. digging depth

m 6.05

6.35

6.65

7.35

Max. reach at ground level

m 9.50

9.75 10.05 10.65

Max. dump height

m 6.55

6.70

6.85

7.05

Max. teeth height

m 9.60

9.75

9.90 10.10

1 Stick 2.40 m, 2 Stick 2.70 m

3 Stick 3.00 m, 4 Stick 3.70 m
at max. attachment offset with vertical ditch walls

Digging Forces

without Quick Coupler

5

6

7

8

Digging force ISO

kN 132

121

112

96

t 13.5

12.3

11.4

9.8

Breakout force

kN 178

178

178

178

t 18.1

18.1

18.1

18.1

with Quick Coupler

Digging force ISO

kN 125

115

107

92

t 12.7

11.7

10.9

9.4

Breakout force

kN 153

153

153

153

t 15.6

15.6

15.6

15.6

Buckets

Machine stability per ISO 10567* (75 % of tipping capacity)

NLC-Undercarriage

SLC-Undercarriage

LC-Undercarriage

WLC-Undercarriage

Stick length (m)

Stick length (m)

Stick length (m)

Stick length (m)

2.40

2.70

3.00

3.70

2.40

2.70

3.00

3.70

2.40

2.70

3.00

3.70

2.40

2.70

3.00

3.70

mm

m

3

kg

850

1)

0.75

620

1,050

1)

0.95

700

1,250

1)

1.15

780

1,400

1)

1.35

860

1,500

1)

1.45

900

1,600

1)

1.55

940

850

2)

0.75

630

1,050

2)

0.95

710

1,250

2)

1.15

790

1,400

2)

1.35

870

1,500

2)

1.45

910

1,600

2)

1.55

950

* Indicated loads are based on ISO 10567 max. stick length, lifted 360° on firm

1)

Standard bucket for direct mounting with teeth Z 40

2)

Standard bucket for mounting to quick coupler with teeth Z 40

Other backhoes available on request
