R 9250
Technical Data
Engine
1 Cummins diesel engine
Rating per
SAE J 1995
����������������
960 kW/1,287 HP at 1,800 rpm
Model
������������������������
Cummins QSK45
(USA/EPA Tier 1)
Type
��������������������������
12 cylinder turbocharged V-engine
after-cooler
two separate water cooling circuits
direct injection system
Displacement
�������������
45 l/2,745 in
3
Bore/Stroke
����������������
159/190 mm / 6.26/7.48 in
or
1 Cummins diesel engine
Rating per
SAE J 1995
����������������
940 kW/1,261 HP at 1,800 rpm
Model
������������������������
Cummins QSK38
(USA/EPA Tier 2 or fuel consumption
optimized setting)
Type
��������������������������
12 cylinder turbocharged V-engine
after-cooler
two separate water cooling circuits
direct injection system
Displacement
�������������
37,8 l/2,307 in
3
Bore/Stroke
����������������
159/159 mm / 6.26/6.26 in
Engine cooling system
������
fans driven via hydraulic piston motor
Air cleaner
�����������������������
dry-type air cleaner with pre-cleaner,
with automatic dust ejector, primary
and safety elements
Fuel tank
�������������������������
5.440 l/1,434 gal
Electrical system
Voltage
����������������������
24 V
Batteries
��������������������
6 x 170 Ah/12 V
Alternator
�������������������
24 V/260 Amp
Engine idling
��������������������
automatic engine idling
Electronic engine
control system
�����������������
engine speed sensing over the entire
engine RPM range. Provides integration
of engine with other machine systems
Hydraulic System
Hydraulic pumps
for attachment and
travel drive
�����������������
3 variable flow axial piston pumps
Max. flow
�������������������
2 x 771 l/min. + 1 x 579 l/min./
2 x 204 gpm + 1 x 153 gpm
Max. hydr. pressure
����
320 bar/4,640 psi
Hydraulic pump
for swing drive
������������
2 reversible swash plate pumps,
closed-loop circuit
Max. flow
�������������������
2 x 352 l/min. / 2 x 93 gpm
Max. hydr. pressure
����
350 bar/5,076 psi
Pump management
����������
electronically controlled pressure and flow
management with oil flow optimisation
Hydraulic tank capacity
�����
2.281 l/602 gal
Hydraulic system
capacity
��������������������������
4.050 l/1,070 gal
Hydraulic oil filter
��������������
1 high pressure safety filter after each high
pressure pump + fine filtration of entire
return flow (15/5 μm)
Hydraulic oil cooler
�����������
cooler with temperature controlled fans
driven via hydraulic piston motor
Electro-Hydraulic Controls
Servo circuit
��������������������
independent, electric over hydraulic
proportional controls of each function
Emergency control
������
via accumulator for all attachment
functions with stopped engine
Power distribution
������������
via monoblock control valves with inte-
grated primary relief valves and flanged
on secondary valves for travel
Flow summation
���������
to attachment and travel drive
Control functions
Attachment and
swing
������������������������
proportional via joystick levers
Travel
������������������������
proportional via foot pedals or hand levers
Bottom dump bucket
��
proportional via foot pedals
Electric System
Electric isolation
���������������
easy accessible battery isolations
Working lights
������������������
high brightness halogen lights:
– 2 on working attachment
– 1 on RHS of uppercarriage
– 3 on LHS of uppercarriage
– 2 on counterweight
Xenon or LED lights in option
Emergency stop switches
��
at ground level, in hydraulic compartment,
in engine compartment and in operator cab
Electrical wiring
����������������
heavy duty execution in IP 65 standard for
operating conditions of – 50 °C to 100 °C/
– 58 °F to 212 °F
Electric Motor (optional)
1 electric motor
Power output
�������������������
1.050 kW/1,408 HP
Type
�������������������������������
3 phase AC squirrel cage motor
Voltage
����������������������������
6,000 V, other voltage on request
Frequency
�����������������������
50 Hz (or 60 Hz)
Revolutions
����������������������
1,500 rpm or 1,800 rpm
Motor cooling
������������������
integrated air-to-air heat exchanger
Starting method
���������������
inrush current limited to 2,2 full load current
Swing Drive
Hydraulic motor
����������������
2 Liebherr axial piston motors
Swing gear
����������������������
2 Liebherr planetary reduction gears
Swing ring
�����������������������
Liebherr, sealed triple roller swing ring,
internal teeth
Swing speed
��������������������
0 – 4.4 rpm
Swing-holding brake
���������
hydraulically actuated, maintenance-free,
multi-disc brakes integrated in each swing
gear
Uppercarriage
Design
����������������������������
torque resistant designed upper frame in
box type construction for superior strength
and durability
Attachment mounting
�������
parallel longitudinal main girders in box-
section construction
Machine access
���������������
(Tier 1) hydraulically driven access ladder
on the cab side of the uppercarriage,
(Tier 2) 45° access system with handrails
on the cab side of the uppercarriage, full
controlled descent in case of emergency
stop
additional emergency ladder fitted near the
cab
