* Details at request
190 kW / 258 hp
S-HD
V mechanically
adjustable
VH-HD hydraulically
adjustable
S-HD
V mechanically
adjustable
VH-HD hydraulically
adjustable
2900 mm 2400 - 2900 mm 2380 - 3300 mm 2900 mm 2400 - 2900 mm 2380 - 3330 mm
21.0 m 21.0 m 21.0 m 23.0 m 23.0 m 23.0 m
2.5 t 2.75 t 3.0 t 2.25 t 2.5 t 3.0 t
• • • — — —
— — — • • •
• • • • • •
• • • • • •
approx. 52 t approx. 55 t approx. 58.5 t approx. 53 t approx. 56 t approx. 59.5 t
240 kW / 326 hp
y VH-HD hydraulically
adjustable
V mechanically
adjustable
S-HD HD-EW
V-HDW mechanically
adjustable
VH-HD hydraulically
adjustable
2380 - 3330 mm 2400 - 2900 mm 2900 mm 3650 mm 2900 - 3400 mm 2380 - 3330 mm
25.6 m 28.0 m 28.0 m 28.0 m 28.0 m 28.0 m
3.0 t 2.25 t 2.25 t 3.0 t 3.0 t 3.0 t
• — — — — —
— • • • • •
• • • • • •
• • • • • •
approx. 74.5 t approx. 64.5 t approx. 66.5 t approx. 69.9 t approx. 73.1 t approx. 75.6 t
R 984 C Litronic *
Engine capacity 504 kW / 685 hp
Undercarriage variant
VH-HDW hydraulically
adjustable
Track gauge 2850 - 3850 mm
Reach height at stick end 37.0 - 65 m
Tool weight at stick end
with reach up to
37.00 m
6.0 t
Tool weight at stick end
with reach up to
65.00 m
2.5 t
Operating weight approx. 220 t
