Range of Versatility.
Characteristic Data and Demolition Equipment Combinations
The useful loads on the stick apply to a slewing range of 360°, including quick coupling system, attachment plate, and add-on tool or special attachment.
R 934 C Litronic
Engine capacity 150 kW / 203 hp
Undercarriage variant S-HD
VH-HD hydraulically
adjustable
Track gauge 2400 mm 2300 - 3200 mm
Reach height at stick end 19.5 m 19.5 m
Tool weight at stick end
with reach up to
8.00 m
2.0 t 2.5 t
Demolition boom 7.50 m • •
Intermediate boom 2.10 m • •
Demolition stick 5.20 m • •
Operating weight approx. 42.5 t approx. 47.5 t
R 944 C Litronic
Engine capacity
Undercarriage variant HD-SL
Track gauge 2600 mm
Reach height at stick end 21.0 m
Tool weight at stick end
with reach up to
10.00 m
2.0 t
Demolition boom 7.30 m •
Demolition boom 9.30 m —
Intermediate boom 2.25 m •
Demolition stick 6.30 m •
Operating weight approx. 48.5 t
R 954 C Litronic
Engine capacity
Undercarriage variant HD
V mechanically
adjustable
S-HD HD-EW
V-HDW mechanically
adjustable
V
Track gauge 2900 mm 2400 - 2900 mm 2900 mm 3650 mm 2900 - 3400 mm
Reach height at stick end 25.6 m 25.6 m 25.6 m 25.6 m 25.6 m
Tool weight at stick end
with reach up to
12.00 m
2.5 t 2.75 t 2.75 t 3.0 t 3.0 t
Demolition boom 8.80 m • • • • •
Demolition boom 11.30 m — — — — —
Intermediate boom 2.50 m • • • • •
Demolition stick 8.55 m • • • • •
Operating weight approx. 60.5 t approx. 63.5 t approx. 65.5 t approx. 69 t approx. 72 t
R 954 C Litronic 34 m
Engine capacity 240 kW / 326 hp
Undercarriage variant
VH-HDW hydraulically
adjustable
Track gauge 2850 - 3850 mm
Reach height at stick end 34.0 m
Tool weight at stick end
with reach up to
14.00 m
3.0 t
Demolition boom 14.50 m •
Intermediate boom 2.50 m •
Demolition stick 11.00 m •
Operating weight approx. 85.5 t
R 974 C Litronic
Engine capacity 400 kW / 543 hp
Undercarriage variant HD-EW
VH-HD hydraulically
adjustable
Track gauge 4588 mm 3400 - 4700 mm
Reach height at stick end 41.0 m 41.0 m
Tool weight at stick end
with reach up to
18.00 m
3.0 t 3.0 t
Demolition boom 17.00 m • •
Intermediate boom 2.70 m • •
Demolition stick 13.50 m • •
Operating weight approx. 127 t approx. 131.5 t
