Liebherr LRB 255 - Manual (Page 11)

11
Due to impr
ovement and engineering pr
ogr
ess we r
eserve the right to change specifications without notice.
All dimensions in mm / inch; only metric values are valid.
MA 35 Rotary for
soil mixing
• Compact design
• Flushing head DN40
• Grout pressure sensor
• Speed sensor
• Drive stub SW 150
• Application as single or double mixing unit
Special features
Basic machines LRB 125 LRB 125XL LRB 155 LRB 255
Specifications MA 35
Max. speed 1st gear 60 rpm
2nd gear 120 rpm
Max. torque 1st gear 35 kNm 25,800 ft.lbs
2nd gear 16.5 kNm 12,900 ft.lbs
Weight* approx. 1000 kg 2,205 lbs
* Without sliding drill head und hose system
491
376
1567
525
90
910
20.67
3.54
35.83
620
19
.33
14
.80
61
.69
24
.41
