HS 885 HD 5
B B
1
L
B B
1
L
*) Other trench widths upon request.
Hydromill options
FD 60 FD 100
FD 60
Trench length
(B)
Trench width
(B
1
)
Length
(L)
Weight
mm mm mm t
3200* 700 - 1200 15400 33 - 37
FD 100
Trench length
(B)
Trench width
(B
1
)
Length
(L)
Weight
mm mm mm t
3200* 800 - 1500 15400 38 - 45
Verticality control
X axis Y axis
Wheels and steering plates Steering plates
Verticality control
X axis Y axis
Wheels and steering plates Steering plates
Torque at
wheel axle
Wheel
speed Suction pump
kNm rpm m³/h
2 x 67 0 - 30 450
Torque at
wheel axle
Wheel
speed Suction pump
kNm rpm m³/h
2 x 99 0 - 27 450
