LHM 600 7
Maximum crane capacity 144 t
Hook operation Grab operation
Outreach on the ropes 4-rope grab motor grab
(m) (t) (t) (t)
13 144.0 75.0 90.0
13 144.0 75.0 90.0
14 144.0 75.0 90.0
15 144.0 75.0 90.0
16 144.0 75.0 90.0
17 144.0 75.0 90.0
18 144.0 75.0 90.0
19 144.0 75.0 90.0
20 144.0 75.0 90.0
22 144.0 75.0 90.0
25 144.0 75.0 90.0
26 141.2 75.0 90.0
28 130.4 75.0 90.0
30 120.0 75.0 85.3
33 106.1 75.0 75.5
34 102.0 72.5 72.5
36 94.8 67.4 67.4
38 88.6 63.0 63.0
40 82.7 58.8 58.8
42 77.3 54.9 54.9
44 72.2 51.3 51.3
46 67.6 48.1 48.1
48 63.5 45.1 45.1
50 59.6 42.4 42.4
Weight ramshorn hook 3.8 t
Weight rotator 3.6 t
Bulk operation
The powerful hydrostatic transmission and advanced Liebherr electronics ensure short, productive working cycles
during bulk handling.
• The Pactronic ® Hybrid Drive System is characterized by an
energy storage device, which is added to the drive system
as a secondary energy source. This results in substantially
higher hoisting and lowering speeds. Not only is the
crane’s efficiency increased, but also the turnover (+30%).
In addition, the crane’s energy consumption is significantly
reduced (-30%).
• During grab operation, hoisting, slewing and luffing are
driven simultaneously at maximized speed to achieve the
highest (possible) turnover.
• During grab filling, features such as automatic lowering
and hoisting guarantee the optimum filling level of the grab.
• The slack rope monitoring system ensures extended
lifetime of the ropes and increases operational safety.
• Reverse power is returned to the drive process through
closed loop hydraulics which results in reduced fuel
consumption.
• The Cycoptronic ® anti-sway system automatically
compensates for all rotational swing, transverse and
longitudinal sway of the load at maximum speeds.
• To provide safe and stress-free working conditions for
the operator, Liebherr offers the Cycoptronic ® including
Teach-In feature, a semi-automatic system, which pilots
the crane from the vessel hatch to the quay without
any sway. Especially for bulk operation into hoppers,
the Teach-In system increases turnover and ensures
consistent turnover rates during the entire ship unloading.
Standard configuration Turnover up to 1500 t per hour
Pactronic ® Turnover up to 2000 t per hour
