Betomix plants

Basic data/type

1.0 1.5 2.25 2.5 3.0

4.5

6.0

Mixer size (cu. m)

1,0

1,5

2,25

2,5

3,0

4,5

6,0

Use of ring-pan mixer

Use of double-shaft mixer

Theoretical output rate for mixed concrete, compacted (cu. m/h)

1)

60

75

100

110

120 160

3)

/ 210

4)

180

3)

/ 260

4)

Theoretical output rate for mixed concrete (cu. m/h)

2)

75

94

125

138

150 200

3)

/ 260

4)

225

3)

/

325

4)

Version with loading elevator

Version with loading conveyor

Number of cement grades

max. 6

Storage volume with inline silo (cu. m)

70 - 300

105 - 500

Mix constituents with inline silo

4 - 10

Storage volume with compartment-type silo (cu. m)

40

-

-

-

-

-

-

Mix constituents with compartment-type silo

4

-

-

-

-

-

-

Storage volume with circular silo (cu. m)

180 - 1010

Mix constituents with circular silo

4 - 12

Storage volume with star-pattern silo (cu. m)

ca. 950

-

-

-

-

Mix constituents with star-pattern silo

4 - 6

-

-

-

-

1) 30-second mixing time

2) 30-second mixing time, compacting factor v = 1.25

3) With discharge from truck mixer

4) With discharge from truck
