Liebherr EP 944 C Stationary Material Handler - Manual (Page 17)

EP 934 C EP 944 C EP 954 C Machine for Industrial Applications 17
Lift Capacities
with Industrial-Type Gooseneck Boom 9.60 m
Height Can be slewed through 360° In longitudinal position of undercarriage Max. reach * Limited by hydr. capacity
The lift capacities are stated in metric tonnes (t) on the lifting gear’s stick tip, and can be lifted 360° on firm, level supporting surface. Capacities
are valid for 600 mm wide triple grouser pads. Indicated loads are based on ISO 10567 standard and do not exceed 75 % of tipping or 87 % of
hydraulic capacity (indicated via *). Lifting capacity of the excavator is limited by machine stability, hydraulic capacity and maximum permissible
load of the load hook.
According to European Standard, EN 474-5: In the European Union excavators have to be equipped with an overload warning device, a load
diagram and automatic check valves on the hoist cylinders, when they are used for lifting operations which require the use of lifting accessories.
Industrial Stick 9.00 m (Variant 3D)
3.0 m 4.5 m 6.0 m 7.5 m 9.0 m 10.5 m 12.0 m 13.5 m 15.0 m 16.5 m 18.0 m 19.5 m 21.0 m
Under-
m carriage m
21.0 Ponton
19.5 Ponton
18.0 Ponton
16.5 Ponton
15.0 Ponton
13.5 Ponton
12.0 Ponton
10.5 Ponton
9.0 Ponton
7.5 Ponton
6.0 Ponton
4.5 Ponton
3.0 Ponton
1.5 Ponton
0 Ponton
– 1.5 Ponton
– 3.0 Ponton
– 4.5 Ponton
– 6.0 Ponton
– 7.5 Ponton
– 9.0 Ponton
– 10.5 Ponton
3.8* 3.8* 9.96
4.6* 4.6* 3.4* 3.4* 11.90
4.3* 4.3* 3.2* 3.2* 13.39
4.2* 4.2* 4.1* 4.1* 3.0* 3.0* 14.57
4.2* 4.2* 4.0* 4.0* 3.6* 3.6* 2.9* 2.9* 15.51
4.2* 4.2* 4.0* 4.0* 3.9* 3.9* 2.9* 2.9* 16.26
4.6* 4.6* 4.3* 4.3* 4.1* 4.1* 3.9* 3.9* 3.4* 3.4* 2.9* 2.9* 16.84
4.8* 4.8* 4.5* 4.5* 4.2* 4.2* 4.0* 4.0* 3.8* 3.8* 2.9* 2.9* 17.27
5.7* 5.7* 5.2* 5.2* 4.7* 4.7* 4.4* 4.4* 4.1* 4.1* 3.8* 3.8* 2.9* 2.9* 17.56
8.7* 8.7* 7.2* 7.2* 6.2* 6.2* 5.5* 5.5* 5.0* 5.0* 4.5* 4.5* 4.2* 4.2* 3.9* 3.9* 3.0* 3.0* 17.72
8.3* 8.3* 13.7* 13.7* 10.1* 10.1* 8.1* 8.1* 6.8* 6.8* 5.9* 5.9* 5.2* 5.2* 4.7* 4.7* 4.3* 4.3* 4.0* 4.0* 3.1* 3.1* 17.75
3.2* 3.2* 9.0* 9.0* 11.2* 11.2* 8.8* 8.8* 7.3* 7.3* 6.2* 6.2* 5.4* 5.4* 4.9* 4.9* 4.4* 4.4* 4.0* 4.0* 3.3* 3.3* 17.65
3.1* 3.1* 6.0* 6.0* 12.0* 12.0* 9.3* 9.3* 7.6* 7.6* 6.5* 6.5* 5.6* 5.6* 5.0* 5.0* 4.5* 4.5* 4.0* 4.0* 3.4* 3.4* 17.42
3.5* 3.5* 5.5* 5.5* 9.9* 9.9* 9.7* 9.7* 7.9* 7.9* 6.6* 6.6* 5.7* 5.7* 5.0* 5.0* 4.5* 4.5* 3.9* 3.9* 3.7* 3.7* 17.05
4.0* 4.0* 5.7* 5.7* 9.0* 9.0* 9.7* 9.7* 8.0* 8.0* 6.7* 6.7* 5.8* 5.8* 5.0* 5.0* 4.4* 4.4* 3.7* 3.7* 3.7* 3.7* 16.54
6.0* 6.0* 8.8* 8.8* 9.5* 9.5* 7.8* 7.8* 6.6* 6.6* 5.6* 5.6* 4.9* 4.9* 4.1* 4.1* 3.7* 3.7* 15.87
9.1* 9.1* 9.0* 9.0* 7.4* 7.4* 6.3* 6.3* 5.3* 5.3* 4.5* 4.5* 4.4* 4.4* 13.69
