Transport dimensions and weights
Transport basic machine
ready for operation, without counterweight.
Transport weight 69,450 lbs
Counterweight
Counterweight
13,230 lbs + 13,230 lbs
Hammer
Transport weight
H 40/2.5 12,350 lbs
Weights
Weight complete 35,280 lbs
Transport leader
includes the leader without working tools (hydraulic hammer,
pre-drill etc.).
The figures include options which are not within the standard scope
of supply of the rig.
Weights can vary with the final configuration of the machine.
41´8´´ 5´6´´ 9´10´´
7´ 18.9´´
