Liebherr L 586 - Manual (Page 7)

Dimensions
Tipping Load, straight / Lifting Force
L 586 2plus2 Block Handling 7
E
F
C
A
D
F max.
F min.
900
G
R1
Stone Fork (2 Tines)
with Quick Change Device
A
Lifting height at max. reach mm
C Max. lifting height mm
E Max. operating height mm
D Height of fork tines at max. lifting height and 45° tipping angle mm
F Reach at loading position mm
F max. Max. reach mm
F min. Reach at max. lifting height mm
G Digging depth mm
Turning circle over external edge of fork mm
R1 Roll back angle
Load Table
A Tipping load, straight
B Lifting force
H Working height
X 900 mm
Y 800 mm
1,935
4,240
5,455
3,010
1,245
1,836
860
290
7,530
50°
500 750 1000 1250 1500 1750 2000 2250 2500 2750 3000 3250 3500 (mm)
27
26
25
24
23
22
21
20
Arbeitshöhe (H)
Kipplast gerade / Hubkraft
( t )
B
A
Y
X
H
The load capacity depends on the dimensions of the marble block and will be calculated when an inquiry is received.
Working Height (H)
Tipping Load, straight
/
Lifting Force
