Liebherr R 956 - Manual (Page 19)

R 956 Litronic 19
Dimensions
LC-Undercarriage
Stick Mono Mono Mono Two-piece
Length Boom Boom Boom Boom
6.70 m 7.60 m 9.20 m 4.70 m
m mm mm mm mm
V 2.35 7,650 7,600 – 8,200
2.90 7,100 8,200 8,750 7,600
3.80 9,300* 7,300 9,000 7,000
5.00 – – 7,750 –
W 2.35 3,900 3,900 – 3,550
2.90 3,950 3,950 4,150 3,650
3.80 3,950* 4,000 4,250 3,950
5.00 – – 4,350 –
X 2.35 12,150 13,200 , – 13,650
2.90 12,200 13,200 14,850 13,550
3.80 12,150* 13,200 14,850 13,550
5.00 – – 14,850 –
HD-Undercarriage
Stick Mono Mono Straight Two-piece
Length Boom Boom Mono Boom
6.70 m 7.60 m Boom 4.70 m
8.00 m
m mm mm mm mm
V 2.35 7,750 7,700 8,350 8,300
2.90 7,200 8,300 7,900 7,700
3.80 9,400* 7,400 8,250 7,100
5.00 – – – –
W 2.35 3,900 3,900 3,550 3,550
2.90 3,950 3,950 3,650 3,650
3.80 3,900* 4,000 3,800 3,950
5.00 – – – –
X 2.35 12,150 13,200 13,750 13,650
2.90 12,200 13,200 13,650 13,550
3.80 12,150* 13,200 13,650 13,550
5.00 – – – –
* without bucket
LC-V-Undercarriage
Stick Mono Mono Mono Two-piece
Length Boom Boom Boom Boom
6.70 m 7.60 m 9.20 m 4.70 m
m mm mm mm mm
V 2.35 7,650 7,600 – 8,050
2.90 7,100 8,200 8,800 7,600
3.80 9,300* 7,300 9,050 6,900
5.00 – – 7,800 –
W 2.35 3,950 3,950 – 3,550
2.90 4,000 4,000 4,200 3,650
3.80 3,950* 4,050 4,300 3,900
5.00 – – 4,400 –
X 2.35 12,150 13,200 – 13,650
2.90 12,200 13,200 14,800 13,550
3.80 12,150* 13,200 14,800 13,550
5.00 – – 14,800 –
LC mm LC-V mm HD mm
A 2,970 2,970 2,970
C 3,315/3,510** 3,390/3,585** 3,335/3,530**
D 3,830 3,830 3,830
E 3,850 3,850 3,850
H 2,925 3,000 2,945
K 1,335 1,410 1,355
L 4,400 4,400 4,500
P 1,160 1,160 1,225
Q 555 760 575
U 5,365 5,365 5,550
S 2,900 2,390/2,890* 2,900
N 500 600 750 500 600 750 500 600 750
B 3,462 3,500 3,650 2,950 2,990 3,140 3462 3,500 3,650
G 3,715 3,715 3,715 3,200 3,200 3,200 3,715 3,715 3,715
Z 6,515 6,515 6,605
* work position
** with FOPS top guard
