Lift chart - fixed jib, Offset 15, Main boom 29 m – Liebherr LR 1300 User Manual
Page 32: Main boom 38 m, Main boom 68 m, Main boom 83 m, Main boom 86 m, Main boom 47 m, Main boom 56 m, Main boom 62 m
32
LR 1300
Lift chart - fixed jib
(No. 1008.xx)
Offset 15°
Capacities in metric tons with fixed jib (No. 1008.xx) 124 t counterweight + 57 t carbody counterweight. Above lift chart is for reference only.
For actual lift duty and complete chart with all available configurations please refer to lift chart in operator’s cab or manual.
Main boom 29 m
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
11
45.0
12
45.0
38.3
14
44.5
37.3
27.0
16
43.8
35.8
25.2
17.6
20
38.9
32.9
22.0
15.7
28
28.9
25.4
17.0
13.2
32
26.8
22.3
15.3
11.7
36
24.1
20.2
13.9
10.7
38
22.9
19.2
13.4
10.2
40
18.3
13.0
9.8
46
11.5
8.7
50
8.2
Main boom 38 m
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
10
45.0
39.2
12
45.0
38.1
28.2
14
45.0
37.0
26.6
18.9
16
43.9
36.2
25.2
17.7
20
40.9
32.7
22.9
16.0
28
33.2
26.5
18.5
13.7
36
27.0
22.0
15.2
11.6
44
23.1
18.9
13.1
10.0
46
22.3
18.2
12.7
9.6
48
17.7
12.3
9.3
55
11.1
8.4
60
7.9
Main boom 68 m
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
7.5
45.0
9
45.0
39.2
11
44.1
38.3
27.8
14
41.5
35.9
26.2
18.4
20
35.7
31.6
23.4
16.2
36
29.2
25.7
18.9
13.4
44
22.5
22.1
16.5
12.3
55
15.0
15.4
14.1
10.6
70
8.6
9.0
9.7
8.9
75
7.2
7.9
8.5
80
6.3
6.9
85
5.5
Main boom 83 m
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
8
42.5
10
40.5
36.8
12
38.7
35.1
26.5
14
36.8
33.6
25.4
17.7
20
31.6
29.6
22.9
15.8
28
28.4
26.1
20.7
14.3
36
28.4
25.4
19.3
13.4
44
21.0
21.2
17.8
12.7
55
13.6
14.0
14.5
11.2
75
5.1
5.5
6.2
6.9
85
2.1
2.5
3.2
3.8
90
2.5
Main boom 86 m
Fixed jib length in (m)
Radius
11
14
17
(m)
t
t
t
8.1
42.0
10
40.1
36.0
11
39.2
35.1
31.6
16
34.8
31.4
28.5
20
30.8
28.8
26.8
28
26.7
24.9
23.7
36
26.7
24.5
22.7
44
20.4
20.8
20.4
55
13.3
13.7
14.2
75
4.7
5.0
5.5
80
3.1
3.5
3.9
85
2.1
2.5
Main boom 47 m
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
9
45.0
40.2
11
45.0
39.2
29.5
13
44.4
38.4
28.0
19.3
16
43.2
36.5
26.0
17.8
20
39.3
33.8
23.7
16.3
28
34.3
28.9
19.9
14.1
36
30.5
26.0
16.7
12.5
44
24.4
21.6
14.5
10.8
50
19.9
19.2
13.2
9.8
55
17.3
12.4
9.1
60
11.6
8.6
65
8.1
Main boom 56 m
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
7.1
45.0
9
45.0
39.6
11
45.0
38.6
28.6
13
45.0
37.6
27.3
19.1
20
38.3
32.8
23.4
16.4
28
34.1
28.5
20.2
14.4
36
32.1
25.9
17.6
13.2
44
23.6
22.3
15.3
11.4
55
16.1
16.5
13.1
9.8
60
13.6
14.0
12.4
9.2
70
10.7
8.3
75
7.9
Main boom 62 m
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
7.3
45.0
9
45.0
39.4
11
44.5
38.5
28.3
14
43.3
36.7
26.4
18.5
20
36.9
32.1
23.4
16.3
36
30.0
25.4
18.4
13.3
44
23.1
22.4
15.9
11.9
55
15.5
15.9
13.7
10.2
65
11.0
11.3
12.0
9.0
70
9.5
10.2
8.6
75
8.6
8.3
80
7.5
Main boom 20 m
Fixed jib length in (m)
Radius
11
14
20
26
(m)
t
t
t
t
13
44.3
14
44.0
34.9
16
40.6
33.1
23.9
17
38.2
32.1
22.8
16.7
18
36.1
30.4
21.7
16.1
20
32.8
27.5
19.9
15.2
24
27.8
24.1
16.9
13.6
28
24.9
20.6
14.8
11.9
30
23.2
19.4
13.9
11.2
32
18.2
13.2
10.6
38
11.4
9.1
44
8.0
