R 944 C Litronic Machine for Industrial Applications 21
Variety of Tools
Multiple Tine Grapples
open tines semi-closed tines closed tines
Grapple Model 69 Capacity m 3 0,80 1,10 0,80 1,10 0,80 1,10
(4 tines) Weight kg 1345 1395 1535 1640 1900 2060
Grapple Model 70 C Capacity m 3 0,80 1,10 0,80 1,10 0,80 1,10
(5 tines) Weight kg 1485 1590 1705 1860 1950 1995
Crane Hook with Suspension
Max. load t 12,5
Height with suspension mm 930
Weight kg 96
For further information see color brochure “Add-on tools for material-handling technology”. To operate a magnet the installation of a generator is
required; please contact your Liebherr dealer or the factory for further information.
Electromagnets with Suspension
Magnet information on request
