L580LogHandler

5

Technical Data

Engine

Dieselengine

�����������������������

D936LA6

Design

�������������������������

Liebherrdieselengine,water-cooled,exhaustturbo

chargedwithintercooler

Cylinderinline

�����������������

6

Combustionprocess

���������

Unitpump(PLD)microprocessorcontrolled

Ratedoutputaccording

toISO9249

�������������������

230kW

at2,000RPM

Max.torque

�������������������

1,320Nm

at1,300RPM

Displacement

�����������������

10.52litres

Bore/Stroke

�������������������

122/150mm

Aircleaner

��������������������������

Drytypewithmainandsafetyelement,pre-cleaner,

serviceindicatoronLCDdisplay

Electricalsystem

Operatingvoltage

������������

24V

Capacity

�����������������������

170Ah

Alternator

����������������������

28V/80A

Startermotor

�����������������

24V/6.6kW

TheexhaustemissionsarebelowthelimitsinstageIIIA/Tier3.

Steering

Design

������������������������������

“Load-sensing”swashplatetypevariableflowpump

withpressurecut-offandflowcontrol.Centralpivot

withtwodouble-acting,dampedsteeringcylinders

Angleofarticulation

���������������

40°(toeachside)

Emergencysteering

���������������

Electro-hydraulicemergencysteeringsystem

Operator’s Cab

Design

������������������������������

Onelasticbearingonrearsection,soundproof

ROPS/FOPScab.Operator’sdoorwithoptional

slidingwindow,180°openingangle,fold-outwindow

onrightsitewithopeningangle,frontwindscreen

madeofcompoundsafetyglass,greentintedas

standard,sidewindowsmadeofsingle-panesafety

glass,greytinted,continuouslyadjustablesteering

columnandjoystickcontrolasstandard,heatable

rearwindow

ROPSrolloverprotectionperEN/ISO3471/

EN474-1

FOPSfallingobjectsprotectionperEN/ISO3449/

EN474-1

LiebherrOperator’sseat

����������

6wayadjustableseatwithlapbelt,vibrationdamping

andsuspensionadjustablefortheoperator’sweight

Cabheatingandventilation

�������

Operator’scabwith4-levelaircontrol,coolingwater

heating,defrosterandairconditioningwithelectronic

valvecontrol,aswellaselectronicfresh/recirculated

aircontrol,filtersystemwithpre-filter,freshairfilter

andrecirculatedairfilter,easilyreplaced,air

conditioningasstandard

Attachment

Geometry

���������������������������

Powerfulandstable“LogHandler”liftingequipment

foroptimumliftingheights.360°rotatinggrappletool

Bearings

����������������������������

Sealed

Brakes

Wear-freeservicebrake

�����������

Self-lockingofthehydrostatictraveldrive(actingon

allfourwheels)andadditionalpump-accumulator

brakesystemwithwetmulti-discbrakes(two

separatebrakecircuits)

Parkingbrake

����������������������

Electro-hydraulicallyactuatedspring-loadedbrake

systemonthetransmission

ThebrakingsystemmeetstherequirementsoftheECguidelines71/320.

Travel Drive

Steplesshydrostatictraveldrive

Design

������������������������

Swashplatetypevariableflowpumpandtwo

variableaxialpistonmotorsinclosedloopcircuitwith

oneaxletransfercase.Directionoftravelinreversed

bychangingtheflow-directionofthevariable-

displacementpump

Filteringsystem

���������������

Suctionreturnlinefilterforclosedcircuit

Control

������������������������

Bytravelandinchingpedal.Theinchingpedalmakes

itpossibletocontrolthetractiveandthrustforces

steplesslyatfullenginespeed.TheLiebherrjoystick

isusedtocontrolforwardandreversetravel

Travelspeedrange

����������������

Speedrange1

����������������������������

0–10.0km/h

Speedrange2andA2

�������������������

0–20.0km/h

SpeedrangeA3

��������������������������

0–30.0km/h

Thequotedspeedsapplywiththetyres775/65R29

GoodyearGP-4D

Axles

Four-wheeldrive

Frontaxle

���������������������������

Fixed

Rearaxle

����������������������������

Centrepivot,with9°oscillatingangletoeachside

Heightofobstacleswhich

canbedrivenover

�����������

520mm

Withallfourwheelsremainingincontactwiththe

ground

Differentials

�������������������������

Automaticlimited-slipdifferentials

Reductiongear

���������������������

Planetaryfinaldriveinwheelhubs

Trackwidth

�������������������������

2,370mmwithalltypesoftyres

Noise Emission

ISO6396

����������������������������

L

pA

(insidecab)

= 69dB(A)

2000/14/EC

�������������������������

L

WA

(surroundnoise)=105dB(A)

Capacities

Fueltank

����������������������������������������������������������������������������������

350l

Engineoil(includingfilterchange)

���������������������������������������������������������

43l

Pumpdistributorgears

��������������������������������������������������������������������

2.5l

Transmission

����������������������������������������������������������������������������

11.5l

Coolant

��������������������������������������������������������������������������������������

52l

Frontaxle

������������������������������������������������������������������������������������

58l

Rearaxle

�������������������������������������������������������������������������������������

50l

Hydraulictank

����������������������������������������������������������������������������

135l

Hydraulicsystem,total

������������������������������������������������������������������

300l

AirconditionsystemR134a

��������������������������������������������������������������

780g

Attachment Hydraulics

Design

������������������������������

“Load-sensing”swashplatetypevariableflowpump

withoutputandflowcontrol,andpressurecut-offin

thecontrolblock

Cooling

������������������������������

Hydraulicoilcoolingusingthermostaticallycontrolled

fanandoilcooler

Filtering

�����������������������������

Returnlinefilterinthehydraulicreservoir

Control

������������������������������

“Liebherr-Joystick”withhydraulicservocontrol

Liftcircuit

���������������������������

Lifting,neutral,lowering

Turningcircle

�����������������������

Forwards,neutral,backwards

Automatictransportconfiguration

Grappleswing

����������������������

Forwardsandbackwards

Grapplerotation

��������������������

360°

Max.flow

���������������������������

400l/min.

Max.pressure

����������������������

320bar

Tyres

Dimensions/weightarecalculatedforloadersequippedwithGoodyear775/65R29

GP-4DL4tyres.

Dimensions/weightwhenfittedwithMichelin800/65R29XLD65L3tyresareamendedto:

Operatingweight

������������

+440kg

Verticaldimensions

����������

+20mm
