Broil King BR-7W - Manual (Page 2)

l
When performing any cleaning or maintenance to this unit, be sure to
unplug from power outlet first, and allow to cool.
l
Call BroilKing Customer Service at 860-738-2200 with any questions or
service needs.
OPERATING INSTRUCTIONS
1. Avoid letting water or food drop or boil over onto heating element.
If liquids or other foreign material are allowed to drip down through
the element pan and into the housing, the warranty is voided.
2. Signal light, on models so equipped, will come on when range is plugged
into electric outlet.
3. This is a light duty range with a 5-1/2” diameter heating element. As with
all countertop ranges as well as stovetops, the most efficient cooking /
heating will be done when using pans that are closest in diameter to the
heating element. The pot or pan used should not exceed the heating
element diameter.
4. Be sure your Portable Buffet Range is resting level on countertop. Avoid
using pans that are unstable and easily tipped.
5. To avoid excessive heat on wall(s) while cooking, always keep a space
of at least 4” between your BroilKing range and your rear and side
walls.
6. To avoid harm to your countertop, place range on a wood cutting board
or hot pad when in use.
CLEANING & MAINTENANCE INSTRUCTIONS
1. Always unplug buffet range from electric outlet and allow to cool before
cleaning.
2. The element hookup configuration has been changed to improve the
longevity of the elements. The new configuration requires a different
procedure to remove the element, if necessary for cleaning. (You may
also clean the elements without removing them by gripping an element
at the point opposite where it goes into the holes in the drip pan and tilting
it up. Do not force it up higher than it will go easily.)
3) To remove an element (Tools needed: pliers and slotted screwdriver):
l
Be sure range is disconnected from electricity and the element is cool.
l
Locate the round push nut on the underside of the unit (directly below
the element you want to remove.) You may need to apply pressure to the
underside of the unit next to the push nut in order relieve the pressure that
holds it in place in order to get a grip on it with pliers.
l
While the pliers are gripping the push nut, use a screwdriver to loosen
and remove the screw in the center of the drip pan.
l
Pull the element up slightly. There are 2 pieces of rubber sleeve on
the wires attached to the element. Gently slide the rubber sleeves back
and remove the element by detaching the "quick-disconnect" terminal.
This is a UL Listed appliance. The following important safeguards are
recommended by most portable appliance manuffacturers.
IMPORTANT SAFEGUARDS
To reduce the risk of personal injury or property damage when using electrical
appliances, basic safety precautions should always be followed, including the
following:
1. READ ALL INSTRUCTIONS BEFORE USE.
2. Do not touch hot surfaces! Always use hot pad or pot holder until unit
cools.
3. To protect against electrical shock, do not immerse cord, plug or appliance
in water or other liquid.
4. Close supervision is necessary when any appliance is used by or near
children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions or has been damaged in any manner.
Contact the BroilKing Factory Service Department at (860) 738-2200
for examination, repair or adjustment.
7. The use of accessory attachments not recommended by the appliance
manufacturer may cause injuries.
8. Do not use outdoors.
9. Do not use appliance for other than intended use.
10. Do not let cord hang over edge of table or counter or touch hot surfaces.
11. Do not place on or near a hot gas or electric burner or in a heated oven.
12. It is recommended that this appliance not be moved when it contains hot
oil or other hot liquid.
13. Always plug cord into wall outlet before turning unit on with control knob.
To disconnect, turn control to "OFF", then remove plug from wall outlet.
14. Do not clean with metal scouring pads. Pieces can break off the pad and
touch electrical parts, creating a shock hazard.
15. A fire may occur if this appliance is covered or touching flammable
material, including curtains, walls, etc., when in operation. To avoid
excessive heat on wall(s) while cooking, always keep a space of at
least 4” between your BroilKing range and your rear and side walls.
SAVE THESE INSTRUCTIONS
This product is for household use only.
IMPORTANT NOTES
l
Electrical connection must be a proper outlet for the 3 pronged cord.
Before connecting power, make sure the voltage and frequency
correspond to the data plate on the unit.
l
A short power supply cord (or cord set) has been provided to reduce the
hazards resulting from becoming entangled in or tripping over a longer cord.
Longer cord sets or extension cords may be used if care is properly exercised
in their use. If a long cord set or extension cord is used, the marked electrical
rating of the cord set or extension cord should be at least as great as the electrical
rating of the appliance. The longer cord should be arranged so that it will not
drape over the counter top or table top where it can be pulled on by children or
tripped over accidentally.
2 3
