42 Navigating the main menu
21.5" (16:9) Displays the input image as if on a 21.5"
monitor of 16:9 aspect ratio.
22"W
(16:10)
Displays the input image as if on a 22"W
monitor of 16:10 aspect ratio.
23"W (16:9) Displays the input image as if on a 23"W
monitor of 16:9 aspect ratio.
Smart
Scaling Adjusts the display size to best suit your needs.
If the Display Mode is 17" , 19"W , or 21.5" , the last 2 scaling
settings (in different resolutions of the input source) will be saved
for quick access.
If the Display Mode is 1:1 (and the resolution of the input source
is lower than 1920 x 1080), the last 5 scaling settings (in different
resolutions of the input source) will be saved for quick access.
0 ~ 100
Color
Format Determines the color space ( RGB or YUV ) based on the
detected video signal.
You might need to manually set the Color Format if colors shown
on the monitor screen do not display properly.
If the input source is HDMI or DP, color format is not selectable.
In other words, Color Format is automatically set depending on
the input video source.
RGB • For D-Sub (VGA) input source from PC.
• For DVI input source.
YUV For D-Sub (Component converted from
VGA) input source from a video device.
HDMI 3D
Format
(XL2420TX
only)
Selects an appropriate format to play 3D content.
Contact your 3D content provider for the correct playback
format.
• 2D
• FramePacked
• Side-by-Side
• Top Bottom
HDMI RGB
PC Range Determines the range of color scales. Select an option that
matches the RGB range setting on the connected HDMI
device. • RGB (0 ~ 255)
• RGB (16 ~
235)
Item Function Range
