BRK electronic FG250B - Manual

9V Battery Powered
S m o k e
AlArm
CAT.
FG225B/FG250B
Description:
BRK Models FG225 and FG250 are single station smoke alarms specifically designed
for residential and institutional applications including sleeping rooms of hospitals,
hotels, motels, dormitories, and other multifamily dwellings as defined in standard NFPA
101. Models FG225 and FG250 have been fully tested and comply with, UL217, CSFM,
NFPA 72, and NFPA 101 and other agencies that model their codes after the above
agencies. They meet building codes where DC (FG225) and DC with Silence (FG250) smoke
alarms are required and with model building codes published by the ICC.
BRK Models FG225 and FG250 are state of the art smoke alarms designed to provide
early warning of a fire. They feature a fully insect screened dual ionization smoke
sensing chamber, an 85dB horn, a supervised 9V battery power supply, a full function
test switch, a silence feature (FG250 only) to silence unwanted nuisance alarms, a
red LED light that indicates DC power or alarm. Each also feature a tamper resistant
locking pin that locks alarm cover to prevent removal of battery. Perfect for apartment,
dormitory or hotel applications. The compact, low profile design complements any
décor. Battery installation and removal can occur while the unit is mounted to the
ceiling or wall via the hinged cover. When voltage drops to a pre-set warning level, the
horn will “chirp” approximately once per minute to indicate a fresh battery is needed.
To insure the battery is always replaced properly, the cover is designed to resist closing
when the battery is missing. Designed for wall or ceiling mounting. Includes mounting
anchors and screws. Both models are approved for use in recreational vehicles.
DUAl IoNIZATIoN
Dual Ionization sensing chamber.
Generally more effective at
detecting small particles produced
by flaming fires. Sources may
include paper or kitchen grease.
SIleNCe FeATUre
(FG250 only) Silences nuisance alarms.
HINGeD CoVer
DeSIGN
Fast and easy installation
and battery replacement
TAmPer reSISTANT
loCkING PIN
Locks alarm cover to prevent
removal of battery. Perfect for
apartment, dormitory or hotel
applications.
9V BATTerY
INClUDeD
APProVeD For
rV USe
Available in the following versions:
FG225B Carbon Zinc Battery
FG250B Silence with Carbon Zinc Battery
FG250AB Silence with Alkaline Battery
FG250LB Silence with Lithium Battery
Listed to
Standard
UL 217
Listed to
Standard
UL 1971
