Quick Start
Factory Programmed Configuration
When the ProMatrix unit is first powered up, the factory default settings are
loaded.
The factory default priority table is listed below. If you want to change any
of these priority levels, you will have to use the ASSIGNMENT function in
the programming mode. See the Programming section of these instructions
(Page 22) to set priority levels.
Input
Priority Level
MIC A
1
MIC B
2
AUX A
3
AUX B
4
(1 = highest, 6 = lowest)
AUX C
5
AUX D
6
The microphone input settings are listed below:
Microphone
Feature
Default
Options
MIC 1
Precedence
VOX
N.O., N.C., VOX
ALC
ON
ON, OFF
Phantom
ON
OFF, ON
MIC 2
Precedence
VOX
N.O., N.C., VOX
ALC
ON
ON, OFF
MIC/TEL
MIC
MIC, TEL
Phantom
ON
OFF, ON
See the Programming section of these instructions (starts on page 22) if
you want to configure the microphones for other than the default values.
