Step 8 – Bowflex SelectTect BDS1642 User Manual
Page 11
Parts:
• Stand assembly from Step 7
• Foot Pegs (#8) or Caster Wheels (#16)
• Hold Down Straps (#9)
8-1 Attach either Foot Pegs (#8) or Caster Wheels (#15) to the Rear Left Stabilizer (#2), the Rear
Right Stabilizer (#3), and both Stand Legs (#4). See Figure 8.
8-2 Attach the Hold Down Straps (#9) to the Left Dumbbell Platform (#5) and the Right Dumbbell
Platform (#6) as shown in Figure 8.
11
step
8
�
��
�
Figure 8
