4
Gigabit Powerline HD Networking Adapter
sections table of contents 2 3 4 1
INTroDUCTIoN
system requirements
• At least 2 HomePlug AV-compatible devices
• Available Ethernet port on each computer or network device
• Available power outlet
• Standard home powerline wiring
• CD-ROM drive
Package Contents
• Two Gigabit Powerline HD Networking Adapters
• HomePlug Quick Installation Guide
• HomePlug User Manual (on CD)
• CD-ROM
• Two RJ45 Ethernet Cables
• Two Wall Plug Adapters
Power leD
Solid Blue Powered on
Off Power off
Blinking Blue Encryption setting up
Solid Blue Encryption setup successful
Double Flash Fail in encryption
Powerline link leD
Color Blue
Link rate excellent: greater than
200Mbps
Color Amber Link rate low: less than 200Mbps
Off No activity
ethernet link leD
Solid Blue 10/100/1000Mbps port linked
Blinking Blue Data transmitting or receiving
Off No Ethernet link
