2
Important Safety Instructions
Read and Save These Instructions
Installation Must Comply With all Local Codes
Please Read Entire Instructions Before Proceeding
Safety Warning
Turn off power circuit at service panel and lock out
panel before wiring this appliance.
REQUIREMENT:
With internal blower: 120V AC, 60Hz. 15A Branch
Circuit.
With remote blower (DAH95 models only): 120V AC
60Hz. 15A Dedicated Branch Circuit.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE
FOLLOWING:
A. Use this unit only in the manner intended by
the manufacturer. If you have questions, contact
the manufacturer. (Bosch Service: 800-944-
2904.
B. Before servicing or cleaning the unit, switch
power off at service panel and lock service
panel. This will prevent power from being
switched on accidentally. When the service
panel cannot be locked, securely fasten a
prominent warning device, such as a tag, to
the service panel.
C. Installation work and electrical wiring must be
done by qualified person(s) in accordance with
all applicable codes & standards, including fire-
rated construction.
D. Sufficient make-up air is needed for proper
combustion and exhausting of gases through
the flue (chimney) of fuel burning equipment
to prevent back-drafting. Follow the heating
equipment manufacturers guideline and safety
standards such as those published by the
National Fire Protection Association (NFPA), the
American Society for Heating, Refrigeration and
Air Conditioning Engineers (ASHRAE), and the
local code authorities.
E. Due to the size and weight of this unit, two
installers are recommended.
F. When cutting or drilling into wall or ceiling, do
not damage electrical wiring or other hidden
utilities.
G. To properly exhaust air, be sure to duct air
outside. Do not vent exhaust air into spaces
within walls, ceilings, attics, crawl spaces, or
garages.
H. Install this hood in accordance with all
requirements specified.
I. Ventilator hood assembly models DAH93 and
DAH94 must be installed with blowers
DHG4001UC (included). Model DAH95 must
be installed with integral blowers DHG4001UC
or DHG6001UC or remote blowers DHG6003UC
or DHG1006UC. Other ventilator blowers
CANNOT be substituted.
Caution
For general residential kitchen ventilating use only.
DO NOT use to exhaust hazardous or explosive
materials or vapors.
Caution
Vent unit to the outside unless using recirculation kit.
Note: If using recirculation kit, refer to
instructions included with that unit.
Parts Included:
1. 4 #8 Sheetmetal Screws
2. Filters (30” models: 2, 36” models: 3)
3. Hood Canopy
4. Remote Blower “Pigtail” Adaptor (DAH95 models only)
5. 7” Transition
6. Spring Type Wire Nuts (rated for a minimum of (2)
#18ga wires and a maximum of 4 #14ga wires, UL &
CSA rated to 600V and 302º F/ 150º C.)
7. Toggle Bolts (2)
8. 6 (30” models) or 12 (36” models) Blunt-Nosed
Sheetmetal Screws
Tools and Parts Needed:
1. 1/2” Conduit w/ Connector
2. Blower (DAH95 models only)
3. Duct Cover (optional)
4. Ducting:
a) DAH93 and 94 models: 7” (8” is also accept-
able, however a 7”-8” transition will also be
required)
b) DAH95 models with remote blower: 10” (7”-
10” transition is also needed. For horizontal
discharge, a custom transition is required.)
5. R20 50W Incancescent Light Bulbs (2), installed
(DAH93 models)
6. 50W Par 20 Halogen Flood Light Bulbs (2), installed
(DAH95 models)
7. Duct Tape
This unit is approved for use with all residential appliances. For residential use only.
Warning
To reduce the risk of fire, use only metal ductwork.
Note: The Bosch ventilation hood referred to throughout this manual is manufactured by BSH Home Appliances Corporation.
