English
introduction
Congratulations on your purchase and welcome to Philips!
To fully benefit from the support that Philips offers, register
your product at www.philips.com/welcome.
This juicer has been designed to maximise the juice output while minimising the cleaning
effort. It has been specifically developed to enable you to process a broad variety of
ingredients and a wide range of recipes with confidence.
general description (Fig. 1)
1 Pusher
2 Feeding tube
3 Lid
4 Filter
5 Juice collector with spout
6 Integrated pulp container
7 Driving shaft
8 Locking arm
9 Motor unit
10 Control knob
11 Cord storage compartment
12 Berry funnel (HR1864,HR1856 only)
13 Juice jug lid with integrated foam separator
14 Juice jug
important
Read this important information carefully before you use the appliance and save it for
future reference.
Danger
- Do not immerse the motor unit in water or any other liquid, nor rinse it under
the tap.
- Do not clean the motor unit in the dishwasher.
Warning
- Check if the voltage indicated on the base of the appliance corresponds to the
local mains voltage before you connect the appliance.
- Do not use the appliance if the plug, the mains cord or other components are
damaged.
- If the mains cord is damaged, you must have it replaced by Philips, a service centre
authorised by Philips or similarly qualified persons in order to avoid a hazard.
- This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
- Children should be supervised to ensure that they do not play with the appliance.
- Never let the appliance operate unattended.
- If you detect cracks in the filter or if the filter is damaged in any way, do not use the
appliance anymore and contact the Philips Consumer care centre for replacement.
- Never reach into the feeding tube with your fingers or an object while the
appliance is operating. Only use the pusher for this purpose.
- Do not touch the small cutting blades in the base of the filter. They are very sharp.
Caution
- This appliance is intended for household use only.
- Do not hold the appliance by the locking clamps when you carry it.
- Never use any accessories or parts from other manufacturers or that Philips
does not specifically recommend. If you use such accessories or parts, your
guarantee becomes invalid.
- For a stable stand of the appliance, always keep the countertop and
the bottom of the appliance clean.
- Make sure all parts are correctly assembled before you switch on the appliance.
- Only use the appliance when the locking clamps are in locked position.
- Only lower the locking clamps to unlocked position after you have switched
off the appliance and the filter has stopped rotating.
- Always unplug the appliance after use.
Electromagnetic fields (EMF)
This Philips appliance complies with all standards regarding electromagnetic fields (EMF).
Fruit and vegetable facts
Depending on the ingredients used, you can prepare up to 2 litres of juice without
emptying the integrated pulp container. When you juice hard ingredients such as
carrots or beetroots, the maximum amount of juice that can be extracted is up to
500ml (check the level indication on the juice jug).
Note: When the integrated pulp container has reached its maximum capacity, pulp ends
up in the juice collector and the juice lid.
If you overfill the integrated pulp container, the appliance becomes blocked.
When this occurs, switch off the appliance and remove the pulp from
the integrated pulp container.
Recipes
Energy cocktail
Ingredients:
- 2 carrots
- ½ cucumber
- 12 spinach leaves
- 1 lime, peeled
- 1 celery stick
- 1 apple
- 1 tomato
- 2 tbsp honey
1 Process all ingredients in the juicer except for the honey.
2 When you have finished processing the ingredients, add honey to the juice and
mix well.
Ordering accessories
To purchase accessories for this appliance, please visit our online shop at
www.shop.philips.com/service. If the online shop is not available in your
country, go to your Philips dealer or a Philips service centre. If you have any difficulties
obtaining accessories for your appliance, please contact the Philips Consumer Care
Centre in your country. You find its contact details in the worldwide guarantee leaflet.
Environment
- Do not throw away the appliance with the normal household waste at the end
of its life, but hand it in at an official collection point for recycling. By doing this,
you help to preserve the environment (Fig. 2).
guarantee and service
If you need service or information or if you have a problem, please visit the Philips
website at www.philips.com/supprt or contact the Philips Consumer Care
Centre in your country. You find its phone number in the worldwide guarantee leaflet.
If there is no Consumer Care Centre in your country, go to your local Philips dealer.
Use the berry funnel to juice for example Gooseberry, Red Bilberry, Viburnum
berries, Sea buckthorn, Wild strawberry, Raspberry, Blackberry, Blackcurrant
or Cranberry.
Preparation
- To extract the maximum amount of juice, always press the pusher down slowly.
- Use fresh fruit and vegetables, as they contain more juice. Pineapples, beetroots,
celery stalks, apples, carrots, spinach, melons, tomatoes, pomegranates, oranges and
grapes are particularly suitable for processing in the juicer.
- The juicer is not suitable for processing very hard and /or fibrous or starchy fruits
or vegetables such as sugar cane.
- Leaves and leaf stalks of e.g. lettuce can also be processed in the juicer.
- Remove stones from cherries, plums, peaches etc. You do not have to remove
cores or seeds from fruits like melons, apples and grapes.
- You do not have to remove thin peels or skins. Only remove thick peels that you
would not eat, e.g. those of oranges, pineapples, kiwis, melons and uncooked beetroots.
- When you prepare apple juice, take into consideration that the thickness of the
apple juice depends on the type of apple you use. The juicier the apple, the thinner
the juice. Choose a kind of apple that produces the type of juice you prefer.
- If you want to process citrus fruits with the juicer, remove the peel as well as the
white pith. The white pith gives the juice a bitter taste.
- Fruits that contain starch, such as bananas, papayas, avocados, figs and mangoes
are not suitable for processing in the juicer. Use a food processor, blender or bar
blender to process these fruits.
Note: When the integrated pulp container has reached its maximum capacity, pulp ends
up in the juice collector, lid and juice.
If you overfill the integrated pulp container, the appliance becomes blocked.
When this occurs, switch off the appliance and remove the pulp from the
integrated pulp container.
