Bush Hog
®
TOUGH
1045 Quick Attach Mid-Mount Loaders
Pin-On Attachment System
BUSH HOG ® TOUGH FeATUreS
TOUGH Boxed Boom Design
TOUGH Large Diameter Cross Tubes
TOUGH robotic Welds
TOUGH High Strength Chrome Plated
Cylinder rods
TOUGH Steel Tube Hydraulic Lines
TOUGH Pivot Pins With recessed Grease Zerks
TOUGH Bush Hog Made Buckets
TOUGH Powder Coat Paint
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE Page 65
MODeL Specifications Based on 1997 ASAE STANDARDS 1045
Tractor PTO HP range 15 - 25
2WD/FWA 2WD/FWA
Maximum Lift Height - Measured at Pivot Pin 86 inches
Maximum Lift Height - Under Level Bucket 81 inches
Maximum Dump Angle 45°
Digging Depth 5 inches
Lift Capacity to Maximum Height At Pivot Pin 825 lbs
Lift Capacity to Maximum Height - 19.5 inches Forward of Pivot Pin 570 lbs
Lift Capacity to 59 inch Height - At Pivot Pin 940 lbs
Lift Capacity to 59 inch Height - 19.5 inches Forward of Pivot Pin 710 lbs
Breakout Force - At Pivot Pin 1335 lbs
Breakout Force - 19.5 inches - Forward of Pivot Pin 965 lbs
rollback Force at Maximum Height - 19.5 inches Forward of Pivot Pin 1935 lbs
rollback Force at 59 inch Height - 19.5 inches Forward of Pivot Pin 2300 lbs
rollback Force at Ground Level - 19.5 inches Forward of Pivot Pin 1700 lbs
raising Time (Ground Level to Full Height) 3.5 seconds
Lowering Time (Full Height to Ground Level) 2.5 seconds
Bucket Dumping Time (Full Rollback to Full Dump) 4.0 seconds
Bucket rollback Time (Full Dump to Full Rollback) 3.0 seconds
Hydraulics Two 1.75 inch Bore, 16.25 inch Stroke Double Acting Bucket Cylinders and
Two 1.75 inch Bore, 13.31 inch Stroke Double Acting Lift Cylinders
Specifications Based on Tractor System of 1875 PSI hyd. Pressure & 6 GPM pump capacity
Pin-On Buckets Only Available in 42, 48 and 60 inch widths
Options Grill Guards
Warranty 1 year limited warranty
FeATUreS Available in major tractor colors
