Installation – Belkin F5U217 User Manual

Page 10

1. Plug the AC adapter into a wall outlet or surge suppressor. Plug the DC

connector into the DC power jack found on the side of the Hub.

Note: The Hub may be used without the power supply when connecting

low-power devices such as keyboards and mice. Remove the USB A cable

connector from its built-in storage bay, then plug it into the downstream port

of your computer, or downstream port of another hub (see Fig. 1).

Important Note: The Hub must be connected to a USB 2.0-compliant host

in order to function in high-speed mode (480Mbps data rate). If the Hub is

connected to a USB 1.1-compliant host, it will operate only in low-speed or

full-speed mode (1.5Mbps/12Mbps).

Installation

Fig.1

Upstream port

Port 1

Port 2

Port 3

Port 4
