4
Dimensions and Speci¿ cations
BASE-RAY TAPPINGS- Tapped 3/4" top and bot-
tom of end sections. A 3/4" x 1/8" vent bushing is
furnished with each Base-Ray Assembly. Only one air
vent location need be used.
Copper tubing is not recommended for steam appli-
cations due to high heat loss through the tubing and
thermal expansion noise.
Base-Ray
®
Assembly Chart
BASE-RAY Assemblies up to and including 6 lineal ft. are
shipped in one piece.
Longer Assemblies are shipped in two or more pieces or sub-
assemblies, none of which exceeds 6 lineal ft.
Maximum recommended length for steam applications is 10
lineal feet.
