MIC-DCA-B Deep
conduit adapter
MIC-501KBD
MIC-PMB pole mount bracket
with MIC-SCA-B shallow
conduit adapter attached
MIC-WKT and MIC-WKT IR washer kits
(tube not included)
MIC-WMB-B with
MIC400 aluminum
attached
10 | MIC series product guide
MIC-SCA-B Shallow conduit
adapter suitable for use with
MIC-WMB, MIC-CMB and
MIC-PMB
MIC-CMB-B corner
mount bracket
Keyboards
MIC series keyboards come in two distinct designs.
The 501 is a robust keyboard that can fully control
a single camera. Due to its compact size it is suitable
for a wide range of applications including rapid
deployment and vehicle mounting. The 516 can
control up to 16 cameras and features a full range of
function keys.
Brackets & accessories
A complete range of mounting brackets is available
including wall, corner and pole mount. Deep and
shallow conduit adaptors give extra flexibility.
Available in standard colors, black, gray and white,
including stainless versions.
Cables
Power, video and telemetry are transmitted through
a single MIC series cable. All cables come complete
with the MIC series connector for easy connection
to the camera head.
PSUs
MIC series PSUs are available in a range of voltage
inputs to provide a perfect fit for virtually any
application. An interface is housed within the PSUs so
an optional alarm card and washer pump drive can be
fitted if required (supplied as standard in IR version
PSUs).
MIC series power supply units
(PSUs), brackets and accessories
MIC series standard PSU MIC series camera –
up to 25 metres cable PSU
Video
out
MIC-516KBD
