Briggs & Stratton Power Products Home Standby Generator
Installation, Start-Up and Owner’s Manual
PARTS LIST - CONTROL PANEL
Item Part #
Description
1
195229GS
ASSY, Control Box
2
195544GS
ASSY, Panel, Control
3
195225GS
PANEL, Back Cover
4
B5133GS
LAMP, LED
5
195555GS
KIT, Battery Charge Circuit w/Clips
6
190818EGS
BREAKER, Circuit, 30A
7
195212GS
RELAY, Plug In
8
*
SCREW, #10 x 5.8"
9
*
WASHER, Shakeproof #6
10 *
PPHMS, #6 - 32 x 3/8"
11 195218GS
SWITCH
12 195006GS
KIT, Fuse Holder w/ Fuse
13 192455GS
BUSHING, Snap 5/8"
14 186173GS
BUSHING, Snap 1-3/8"
15 186582GS
BUSHING, Snap 7/8"
16 195007GS
KIT,Wire Harness with Crimp Nut
17 *
HHCS, M6 - 1.0 x 30
18 195009GS
KIT, Plastic Clips
19 *
SCREW, 12 -24 x 1/2 Thd Forming
20 *
WASHER, Shakeproof
21 *
BOLT, Swage, 1/4 - 20 x 1/2
22 193171GS
WIRE-A, 6AWG, Red
23 691656
CONTACTOR, Starter
24 194659GS
WIRE-A, 6AWG, Red
25 194251GS
KIT, Hardware Starter Contact
26 188573AGS
WIRE-A, Series w/2 Ring Lug
27 194250GS
KIT, J-Bolt/Strap with Hardware
28 193347GS
KIT, Battery Hardware
29 188443GS
BATTERY
30 193291GS
REGULATOR, Fuel
31 186151GS
FITTING, Elbow, 3/4 NPT
Item Part #
Description
32 186148GS
HOSE, Gas, Reg. to Valve
33 186150GS
FITTING, Elbow, 3/8 NPT
34 195005GS
KIT, Hose, Reg to Engine w/Clamps
35 193537CGS
WIRE, 18 AWG, Blue
36 192449GS
FITTING, Nipple, 3/4 x 2
37 B4773GS
SOLENOID, Gas Fuel
38 186345GS
TERMINAL, Ground
39 186647GS
DECAL,Warning, Outdoor Install
40 190992GS
DECAL,Warning Electrical Shock
41 186645GS
DECAL, Caution, Shock
42 65795GS
RECTIFIER, Battery Charge
43 B4986GS
DECAL, Ground
44 *
NUT, M6 - 1.0
45 *
WASHER, Lock, 1/4
46 186641GS
DECAL, Operating Instructions
47 *
SCREW, 10 x 32 x 1 Phillips Truss
Head
48 *
WASHER, Lock, M5
49 *
NUT, M5 - 0.8
50 194096GS
STRIP,Terminal 6 Pole
51 *
PPHS, #6-32 x 5/8
52 *
WASHER, M3
53 *
WASHER, Lock, M3
54 *
NUT, M3 - 0.5
55 195559GS
ASSY,Terminal Block
56 *
PPHS, #8 - 32 x 1/4",Trilobular
57 *
NUT, 1/4 - 20
58 *
WASHER, Shakeproof Int. 1/4 - M6
* - Items without part numbers are common fasteners and
are available at local hardware stores.
