Operation
39
Pro-Picture menu
Some picture adjustments are available only when certain input sources are in use.
Unavailable adjustments are not shown on the screen.
FUNCTION
(default
setting / value)
DESCRIPTION
Keystone (0)
Corrects any keystoning of the image. Refer to
for more information.
Auto Resize
(on)
Automatically resizes the input signal pixel resolution to the native resolution
of the projector.
On: The pixel resolution of the input signal is converted to the native
resolution of the projector (800 x 600). For input signals with lower
resolutions, gaps in the pixels are automatically interpolated into the image
before being projected. This may distort the image clarity.
Off: If larger than the native resolution of the projector, the image is resized to
fit within the display area. Some resolution may be lost. For input signals with
lower resolutions, the projected image will display smaller than if resized to full
screen. You could adjust the zoom setting or move the projector towards the
screen to increase the image size if necessary. You may also need to refocus the
projector after making these adjustments.
Aspect Ratio
(Native)
There are three options to set the image's aspect ratio depending on your input
signal source.
See
"Selecting the aspect ratio" on page 28
for details.
H Position
(0)
Adjusts the horizontal position
of the projected image.
V Position
(0)
Adjusts the vertical position of
the projected image.
Phase
(depends on
the selected
input
source)
Adjusts the video input clock to synchronise with
the video signal. This helps reduce image distortion
produced by some PC video timings.
H Size (0)
Adjusts the horizontal width of the image.
-30
+30
-30
+30
