Outdoor LP Gas Barbecue Grill Model No. HBT601B Contact 1.800.762.1142 for assistance. Do not return to place of purchase.
page no.
5
Step
6
Attach left and right side shelves
A. Loosen pre-attached screws.
B. Insert keyhole opening on side shelf onto loosened screw.
C. Attach left and right side shelves to grill body assembly using 4 sets of bolts (C),
lock washers (E), and washers (D).
D. Tighten all screws.
Step
7
Attach regulator
Attach regulator to right side shelf using 2 small screws (A).
Step
8
Attach tank support
Attach tank support to right side shelf, by sliding hook on tank support through
opening, rotate into place.
Step
9
Attach ignitor
Attach ignitor wires to ignition box.
Step
10
Insert heat plates
Insert heat plates into grill body assembly.
Note: locate the “UP” embossed in the plates for orientation.
Step
11
Insert cooking grid
Insert cooking grid into grill body assembly.
