FEATURES
• Get an instant ceramic-tip fiber
connection.
• Prepolished Fiber Connectors handle ST,
SC, FC, LC, and MT-RJ connections.
• Prepolished fiber connectors are
comprised of the connector housing,
two sleeves, and two compression-hood
fittings.
• One push with the Fiber Optic Cleaver
(FT538) cuts fiber cable cleanly.
• Stress-free splicing! No gluing or
alignment problems with the No-
Adhesive Mechanical Splice (FO030).
• Hold up to six splices securely in the
Mechanical 6-Splice Tray (WP602).
OVERVIEW
Get ready for the easiest fiber connections you’ve ever
made with the Fiber Connector Tool Kit and Prepolished
Fiber Connectors.
The rotating cam on the ST ® and FC Prepolished Fiber
Connectors makes termination quick and smooth.
All connectors come with a fiber optic stub in the
connector tip, which is cemented firmly in place. The stub
is polished to a physical-contact (PC) finish. Because the
connectors are prepolished, you get the strength of a bonded
connection without polishing and epoxy during installation.
That makes it easy to get peak performance.
The connector housing is designed to make matching up
the fiber stub and cable easy. Insert a stripped and cleaved
fiber cable in the connector, and when you feel little or no
resistance, the fiber and stub and are matched up correctly.
Then just crimp!
Mechanical Splice and Tray
To splice fiber cables, choose the No-Adhesive Mechanical
Splice. Insert a stripped and cleaved fiber cable into each end
of the splice and twist. A cam locks the fibers into position
for accurate alignment. To protect and organize your splices,
use the Mechanical 6-Splice Tray. The tray holds six spliced
connections securely.
NOTE: You can also order the tools separately.
NOTE: FO041–FO044 are also available in 10-packs. For details,
contact our FREE Tech Support.
FT535-R2:
✦ Installation Tool/Bench Clamp, Crimp Tool,
and Fiber Optic Cleaver
✦ Assembly manual and video
✦ Buffer tube stripper
✦ Ruler, strip-length gauge, scissors, and tweezers
✦ Electrical tape, alcohol wipes, and marker
WHAT‘S INCLUDED
Item Code
Fiber Connector Tool Kit FT535-R2
For the connectors you need, order…
Prepolished Fiber Connectors
Multimode, 62.5-Micron
ST FO031-R2
SC FO032
FC FO033
LC FO035
MT-RJ FO034
Multimode, 50-Micron
ST FO041
SC FO042
LC FO043
MT-RJ FO044
Single-Mode
ST FO036
SC FO037
FC FO038
MT-RJ FO039
For individual tools, order…
Installation Tool/Bench Clamp FT545
Crimp Tool FT546
Fiber Optic Cleaver FT538
No-Adhesive Mechanical Splice, 6-Pack FO030
Mechanical 6-Splice Tray WP602
