5
Powerline AV Networking Adapter
sections
table of contents 1 3 4
INsTALLINg ANd seTTINg UP The AdAPTers
2
overview
Installation of the VideoLink Powerline Internet Adapter takes only
seconds and does not require setting up long wires throughout the
house. Simply plug the units directly into any available wall outlet and
connect to any device with an Ethernet port. Users have the option to
randomly change the security password for their powerline network.
hardware setup
1. Plug your network cable into the device’s RJ45 network
adapter port.
2. Plug the other end of your network cable into the RJ45 port located
at the back of the Adapter.
3. Insert the Adapter directly into a power outlet in the wall.
NoTe: do not plug the device into a UPs or power strip with
surge protection as they may filter the powerline signal.
4. Repeat this process for the second Adapter.
