Installing Mounting Brackets
Install all mounting brackets on the tractor according to instructions packed with mounting kit.
NOTE: Leave all hardware loose until the loader is completely assembled to facilitate assembly and proper
loader alignment.
Installing Side Frames
Position hinges (30) inside of side frames (13 & 14). Install 5/8 x 4-1/2 carriage bolts (35) as shown and secure
with lock nuts (36).
Position side frames (13 & 14) over the loader mounting brackets and secure with hardware according to
instructions packed with mounting kit.
Installing Grease Fittings
Install 1/4 x 45 grease fittings (12) into the rod end of bucket cylinders. Install 1/4 straight grease fittings (4) into
the tube at bucket end of lift boom arms. Also install 1/4 straight grease fittings (4) into base and rod ends of lift
and bucket cylinders.
Install Bucket
Attach bucket to lift boom frame and bucket cylinders with 1” x 4-3/8” pins (6), 3/8 x 1” shoulder bolts (9) and
lock nuts (7).
