BEA Stanley Dip Switch I User Manual
Page 9
SIZE:
DRAWN BY:
B
100 ENTERPRISE DRIVE
PITTSBURGH, PA 15275
PHONE: (412) 249-4100
FAX: (412) 249-4101
EMAIL: www.beasensors.com
REV BY:
KJG
KJG
SCALE:
DATE:
NONE
16 NOV 2005
PART NO:
SHEET
1 OF 1
NOTES: 1 ) MAGIC FORCE AUX. SWITCH #4 SHOULD OPEN AT APPROX. 65-70 DEGREES. FOR MAGIC SWING REFER TO INHIBIT SWITCH BEA PT# 10 SSINHL OR 10SSINHR
2 ) SHOWN LH,RH MAGIC SWING AND RH MAGIC FORCE FOR LH MAGIC FORCE REVERSE RED AND BLACK WIRES.
3 ) DOOR CONTROL SW2 SWITCH BANK SET DIPSWITCH # 1 & 3 TO THE OFF (TIMER) POSITION.
4 ) LO21S DIPSWITCHES: 1-5 (LOCK-OUT TIMING), #6-8 (NOT USED)
5 ) STALL ADJUSTMENTS MAY NEED TO BE INCREASED FOR LO21S OPTIMUM OPERATION.
RIGHT APPRCH SIDE SSCAN
LEFT APPRCH SIDE SSCAN
EAGLE
N.C. 5
N.O. 4
green
COM 3
white
POWER 2
black
POWER 1
red
TITLE: STANLEY MP CONTROL, MAGIC FORCE,
WITH LO-21S, PARALLAX II SYSTEM
Q-DISCONNECT ON APPROACH SIDE
80.0148.01
LEFT SAFETY SIDE SSCAN
RIGHT SAFETY SIDE SSCAN
BODYGUARD
RED
GREEN
OFF
ON
LO21S
YELLOW
GRAY
BLUE
RED
BLACK
STANLEY MP
CONTROL
YELLOW
ORANGE
VIOLET
HOLD OPEN
AUTO
OFF
BLACK
WHITE
24 V
TRANSFORMER
Common
N/O
N/C
AUXILIARY
SWITCH #4
SEE NOTE 1
IF AFTER TROUBLESHOOTING A PROBLEM, A SATISFACTORY SOLUTION CANNOT BE ACHIEVED, PLEASE CALL B.E.A., INC. FOR FURTHER ASSISTANCE DURING EASTERN STANDARD TIME
AT 1-800-523-2462 FROM 8AM - 5PM. FOR AFTER-HOURS, CALL EAST COAST: 1-866-836-1863 OR 1-800-407-4545 / MID-WEST: 1-888-308-8843 / WEST COAST: 1-888-419-2564. DO NOT LEAVE
ANY PROBLEM UNRESOLVED. IF YOU MUST WAIT FOR THE FOLLOWING WORKDAY TO CALL B.E.A., LEAVE THE DOOR INOPERABLE UNTIL SATISFACTORY REPAIRS CAN BE MADE. NEVER
SACRIFICE THE SAFE OPERATION OF THE AUTOMATIC DOOR OR GATE FOR AN INCOMPLETE SOLUTION.WEB: WWW.BEASENSORS.COM
MOTOR
-
+
