Brinkmann ProSeries 8445 User Manual
Page 30
Step 16
Place the bezel over the control
knob mounting stem and position
over holes in side burner base
and side burner valve assembly.
Attach with two M4 X 10mm bolts
with washers which come with
valve. Install the side burner
control knob onto valve stem,
then tighten up the burner
assembly / bracket screws
loosened in Step 14.
Step 17
Attach side burner igniter lead wire
to the electrode as illustrated.
Step 18
Place side burner grate over side
burner.
29
Side Burner
Igniter Lead
Electrode
