Specifications PRi665CV PRi685CV PRi85SubCV
Frequency Response (±3dB) 60Hz–18kHz 55Hz–18kHz 38Hz–150kHz
Audio Input Range 0Hz–0kHz 0Hz–0kHz 0Hz–0kHz
Maximum Power (70V amplifier) 65 watts 65 watts 65 watts
Maximum Power (100V amplifier) 65 watts 65 watts 34 watts
Maximum Power
(DirX connection)
90 watts 100 watts 100 watts
Nominal Impedance
(Dir\DirX connection)
8 ohms 8 ohms 4 ohms
Switch Settings
(70V)
64W, 3W, 16W, 8W, 4W and Dir x (non-70V/100V) 64W, 3W, 16W, 8W (70V)
Dir and Dir X (non-70V)
(100V) 64W, 3W, 16W, 8W, 4W and Dir x (non-70V/100V) 34W, 16W, 8W (100V)
Dir and Dir X (non-100V)
Sensitivity (.83V @ 1M) 88dB 89dB 88dB
Bass Unit 6” (153mm) 8” (04mm) 8” (04mm)
Tweeter 3 ⁄
4
” (0mm) soft dome 1” (5mm) soft dome NA
Crossover Frequency 3,600Hz 3,500Hz 130Hz
Grille Frame Diameter 11 3 ⁄
8
” (89mm) 13 3 ⁄
4
” (350mm) 13 3 ⁄
4
” (350mm)
Mounting Hole Cutout 9 15 ⁄
16
” (53 mm) 1 3 ⁄
8
” (314mm) 1 3 ⁄
8
” (314mm)
Mounting Depth (with 1/” dry wall) 9 3 ⁄
8
” (39mm) 11 3 ⁄
4
” (99mm) 11 3 ⁄
4
” (99mm)
Weight 11 lbs (5.0kg) 19 lbs (8.6kg) 18 lbs (8.kg)
Maximum Ceiling Height 18 feet (5.5m) feet (6.7m) feet (6.7m)
