Doughnut Fryer Replacement Parts
14
Figure 4. Drain Valve and Handle Assembly
Table 4. Drain Valve and Handle Assembly Parts
ITEM # PART # QTY DESCRIPTION
1 D0060 1 VALVE, DRAIN SS BALL&PLT.CAR.STEM
2 MA18000508 1 HANDLE, DRAIN VALVE DNF
3 F0253 1 PIN, CLEVIS 3/16 X 1 3/4
4 F0254 2 PIN, COTTER HAIRPIN #213
5 FT0543 1 DRAIN VALVE BRACKET, FRYERS
6 SP0034 2 SPACER, DRAIN VALVE BRKT FRYERS
7 C0672 1 COVER, DRAIN HANDLE RED
8 CA0003 1 SWITCH ENGAGING BLOCK
9 DNFFA018 1 MICROSWITCH BOX
10 S0073 1 SWITCH, PUSHBUTTON MICRO
