BKI DNF-F User Manual
Page 13
Doughnut Fryer
Replacement Parts
11
Table 1. DNF/DNF-F Assembly & Components List
PART #
QTY
DESCRIPTION
FIGURE (ITEM #)
TABLE
DNFA023
1 COVER, THERMO BULB
Figure 1 (1)
Table 1
DNFA040
2 BRACKET, CALROD COVER DNF
Figure 1 (2)
Table 1
DNFA065
2 CASTING, CALROD BRKT
Figure 1 (3)
Table 1
SB1817
Or
SB7718
1 UPPER CONTROL PANEL 208V DNF, DNFF
Or
UPPER CONTROL PANEL 240V DNF, DNFF
Figure 1 (4)
Figure 2
Table 1
Table 2
R0003
2 RELAY, 4 POLE 240V
Figure 1 (5)
Table 1
DNFA069
1 CASTING, RH HINGE
Figure 1 (6)
Table 1
DNFA024
1 DRAIN, FLIP STOP
Figure 1 (7)
Table 1
SB1834
or
SB1804
1 DRAIN BOARD ASSY, LS DNF
or
DRAIN BOARD ASSY, RS DNF
Figure 1 (8)
Table 1
FKMA399
2 SIDE CABINET, L&R FKM/DNF
Figure 1 (9)
Table 1
DNFA016
1 DRAIN BOARD ROD
Figure 1 (10)
Table 1
DNFA039
2 BRACKET, DRAIN BOARD ANGLE
Figure 1 (11)
Table 1
C0406
4 CASTER, W/TOP PLATE 5"
Figure 1 (12)
Table 1
AN18000100
1 MOTOR & PIPING ASSY DNFF FLEXLINE
Figure 1 (13)
Figure 3
Table 1
Table 3
-
1 DRAIN VALVE & HANDLE ASSY
Figure 1 (14)
Figure 4
Table 1
Table 4
SB1801
or
SB1835
1 LOWER CONTROL PANEL 208V DNF
or
LOWER CONTROL PANEL 240V DNF
Figure 1 (15)
Figure 5
Table 1
Table 5
SB7717
1 COMPLETE OIL VAT ASSY DNF-F
Figure 1 (16)
Figure 6
Table 1
Table 6
SB7700
or
SB1807
1 FRAME WELD, DNF-F
or
FRAME WELD, DNF
Figure 1 (17)
Table 1
H0052
1 HINGE, DOOR, LH, NO PIN FRYER DOORS
Figure 1 (18)
Table 1
H0051
1 HINGE, DOOR, RH, NO PIN FRYER DOORS
Figure 1 (19)
Table 1
SB1826
1 DOOR ASSY DNF DNF-FF
Figure 1 (20)
Figure 7
Table 1
Table 7
SB1953
1 OUTLET BOX, (DNF ONLY)
Figure 1 (21)
Table 1
RC0015
1 RECEPTACLE, 6-20 SGL HD (DNF ONLY)
Figure 1 (22)
Table 1
C0651
1 COVER, SINGLE RECEPT. (DNF ONLY)
Figure 1 (23)
Table 1
SB1813
or
WN18000200
1 VAT WELDMENT, DNF
or
WELL WELD DNFF
Figure 1 (24)
Table 1
DNFA007
1 SHIELD, CALROD
Figure 1 (25)
Table 1
DNFA068
1 CASTING, LH HINGE
Figure 1 (26)
Table 1
C0024
or
C0025
3 CALROD, 208V 2850W
or
CALROD, 240V 2850W
Figure 1 (27)
Table 1
