CHASSIS PARTS
For Model: WFE720H0AS0
(Stainless)
W10501916
Illus. Part
No. No. DESCRIPTION
1 W10322770 Panel, Side
2
3196178 Screw
3 W10289145 Rack, Bottom
4 W10306542 Bracket, Anti−Tip
5 W10273169 Main Back
6
3186034 Bracket, Service
7 3196548 Fuse, Thermal
8 W10362924 Screw
9
9761301 Screen, Catalyst
10 W10245259 Block, Terminal
11
311255 Bulb, Oven
12 W10346154 Cover, Convection
13 W10273002 Bracket, Support
14 W10289097 Element, Bake
3600W
15 W10346147 Pan, Bake
16
3196701 Assembly, Light
17 W10031780 Screw
18
9757262 Switch, Door
19 W10273192 Rod, Rear Door
20 W10341186 Assembly, Foot
21 W10058460 Foot, Rear
22
3196172 Screw
23 W10289099 Shield, Heat
24
9758701 Spacer, Door
25 W10211455 Element, Broil
3600W
26 W10181986 Sensor, Oven
27 W10134285 Vent, Oven
28 W10289077 Receiver, Hinge
29 W10289079 Bottom, Oven
30
Rail, Base
W10390007 Left Hand
W10390008 Right Hand
31 W10035900 Support,
Oven Bottom
32 3196165 Screw
33 7101P485−60 Screw, Anti−Tip
34 W10389553 Fan, Convection
35 W10326122 Cover,
Terminal Block
36 7103P027−60 Nut,Terminal Block
37 W10162385 Gasket, Door
38 W10137382 Clip, Base Rail
39 W10179196 Rack, Oven
40 W10205526 Rack, Oven
(Partial)
41 W10186592 Rack, Oven
(Insert)
INSULATION
W10194393 Insulation, Wrap
W10225524 Insulation, Back
W10225523 Insulation, Bottom
W10281322 Block, Bare Wire
Adapter Kit
4820F015−59 Strap, Insulation
