POWERSCREW AND RAM PARTS
Illus.
No. Part No. Description
1 9870500 Screw, Power
Complete Assembly
2 Screw, Power
(Available Only As
Complete Assembly)
3 779121 Plate, Bearing
4 775482 Bearing, Needle
5 776941 Hub, Power Screw
6 775481 Race, Thrust
7 777385 Sprocket, Washer
8 4154842 Nut, Power Screw
9 777332 Washer, Cone
10 9871067 Screw
11 9871251 Ram Assembly
12 9870163 Nut, Power
13 9870187 Stud
14 9870037 Stop, Ram
Powerscrew
15 9870498 Bracket, Top Limit
Switch
16 489399 Screw
17 9870775 Cap, Stop
18 9870169 Slide, Ram
19 8534092 Clip
201210002 7 Part No. W10546249 Rev. A
