UPPER OVEN PARTS
4
For Models:WOD93EC0AB00, WOD93EC0AW00, WOD93EC0AS00, WOD93EC0AE00, WOD93EC0AH00
(Black) (White) (Stainless) (Black Ice) (White Ice)
W10484747
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 W10347649 Spacers, Front
2 W10282946 Tube, Cavity Tube
3 W10282975 Receiver, Hinge
4 W10351258 Bracket,
Blower Deflector
5 W10314880 Latch, Motorized
Blower Deflector
6 W10282980 Chassis, Top
7 W10260262 Indicator, Light
8 W10412722 Lens, Light
9 W10412711 Bulb, Light
10 W10283040 Vent, Center
30" Double
11 W10282960 Gasket
12 W10282985 Exhaust,
Vent Cover
13 W10318190 Chassis, Side
14 W10282990 Chassis, Back
15
Liner, Oven
(Not Serviceable)
16 7430P043−60 Sensor
17 W10392683 Bumper, Rail
18
4449751 Thermostat
19 W10282900 Chassis, Base
20
Assembly,
Bottom Vent
W10327373 Black
W10351279 Stainless
21 W10283008 Chassis,
Bottom Duct
22 Trim, Bottom Vent
W10351236 Black
W10327377 Stainless
23 W10213759 Support,
Air Channel
24 W10351308 Chassis, Bottom
Duct Spacer
25 W10351283 Bracket, U−Shape
26 W10254050 Screw
27
7101P426−60 Screw
28 4450038 Screw
29 W10283016 Grommet,
Front Frame
30 W10282984 Base,
Exhaust Vent
31 W10318196 Chassis, Back
Duct Upper
32 W10283000 Chassis,
Back Duct
33 4451758 Block, Foam
34 W10351278 Bumper & Screw
35 W10283036 Vent, Top 30"
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
W10282942 Insulation, Wrap
W10282944 Insulation, Cavity
