Front Panel Layout

USB

Function Button

Power Switch

Power LED

Function LED

Disk LEDs

(Green-Access

Red-Error)

Note: The LinkStation’s front panel is removable by pulling

it straight forward. Do not lift the unit by its front panel. It

may come off suddenly, allowing the unit to fall.
