UPPER OVEN PARTS
Illus.
No. Part No. Description
1 W10347649 Spacers, Front
2 W10282946 Tube, Vent
3 W10282975 Receiver, Hinge
4 W10351258 Bracket, Blower
Deflector
5 W10314880 Latch, Motorized
6 W10282980 Top, Chassis
7 W10260262 Light, Indicator
8 W10412722 Lens, Light
9 W10412711 Bulb, Light
10 W10283040 Vent, Center 30"
Double
11 W10282960 Gasket
12 W10282985 Exhaust, Vent Cover
13 W10318190 Side, Chassis
14 W10282990 Back, Chassis
15 Liner, Oven (Not
Serviceable)
16 7430P043-60 Probe, Sensor
17 W10392683 Bumper, Rail
18 4449751 Thermostat (TOD)
19 W10282900 Base, Chassis
20 Assembly, Bottom
Vent
W10327373 Black
W10351279 Stainless
21 W10283008 Chassis, Bottom Duct
22 Trim, Bottom Vent
W10351236 Black
W10327377 Stainless
23 W10213759 Support, Air Channel
24 W10351308 Chassis, Bottom Duct
Spacer
25 W10504028 Bracket, U-Shape
26 W10254050 Screw
27 7101P426-60 Screw
28 4450038 Screw
29 W10283016 Grommet, Front
Frame
30 W10282984 Base, Exhaust Vent
Illus.
No. Part No. Description
31 W10318196 Chassis, Back Duct
Upper
32 W10542857 Duct, Chassis Back
33 4451758 Block, Foam
34 W10351278 Bumper & Screw
35 W10283036 Vent, Top 30"
Following Parts Not
Illustrated
W10520715 Insulation, Wrap
W10282944 Insulation, Cavity
12/005/2012 5 Part No. W10564795 Rev. A
